Поддържани процесори:
Intel® Socket LGA1200 for 11th Gen Intel® Core™ Processors & 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
Supports Intel® 14 nm CPU
CPU Socket:
Intel LGA1200
Чипсет:
Intel Z590
Максимален капацитет RAM памет:
up to 128 GB (32 GB single DIMM capacity) of system memory
Поддръжка на Dualchannel:
Да
Поддържана памет:
DDR4
Честота памет:
11th Generation Intel® Core™ i9/i7/i5 processors: Support for DDR4 5333(O.C.) / DDR4 5133(O.C.) / DDR4 5000(O.C.) / 4933(O.C.) / 4800(O.C.) / 4700(O.C.) / 4600(O.C.) / 4500(O.C.) / 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz 10th Generation Intel® Core™ i9/i7 processors: Support for DDR4 2933/2666/2400/2133 MHz memory modules 10th Generation Intel® Core™ i5/i3/Pentium®/Celeron® processors: Support for DDR4 2666/2400/2133 MHz memory modules
M.2 слот:
1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_CPU) (Note) Chipset: 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2A_SB)
Поддръжка на RAID:
SATA RAID 0, 1, 5, 10
Графична карта:
Intel HD Graphics
Graphics технология:
CrossFire
Вграден Bluetooth:
Не
Wi-Fi Mодул:
Не
Други:
Bios: 256 Mb Flash ROM, UEFI AMI BIOS
Форм фактор:
ATX
Гаранция (месеца):
36
