| Manufacturer | CISCO | |
| Manufacturer Part No | C9200-48P-E | |
| Marketing Description | |
| The Catalyst 9200 series delivers the superior features. It's highly secure and always on, and it provides IT simplicity, resulting in a great experience every time. | |
| Product Features | |
|
|
| General | |
| Device Type | Switch - 48 ports - smart - stackable |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 48 x 10/100/1000 (PoE+) |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 740 W |
| Performance | Wireless bandwidth: up to 48 Gbps Switching capacity: 176 Gbps Forwarding rate: 261.9 Mpps |
| Capacity | Virtual networks: 4 MAC addresses: 32000 IPv4 routes: 14000 Indirect IPv4 routes: 4000 Direct IPv4 routes: 10000 IPv4 routing table entries: 4000 IPv6 routing table entries: 2000 Multicast scale: 1000 ACL scale entries: 16000 Packet buffer size: 6 MB Flexible NetFlow entries: 16000 VLAN IDs: 1000 |
| Jumbo Frame Support | 9198 bytes |
| Routing Protocol | OSPF, RIP, IS-IS, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng, MSTP |
| Remote Management Protocol | NETCONF, RESTCONF |
| Features | Quality of Service (QoS), Remote Switch Port Analyzer (RSPAN), Flexible NetFlow (FNF), MACsec support, Control plane protection (CoPP), Sampled NetFlow, Switched Port Analyzer (SPAN), Embedded Event Manager (EEM), First Hop Security (FHS), DNA support |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, IEEE 802.3bz |
| RAM | 4 GB |
| Flash Memory | 4 GB |
| Expansion / Connectivity | |
| Interfaces | 48 x 1000Base-T RJ-45 PoE+ - 30 W |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Power Provided | 1000 Watt |
| Voltage Required | AC 100-240 V |
| Miscellaneous | |
| MTBF | 375,570 hours |
| Compliant Standards | CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35 |
| Software / System Requirements | |
| OS Required | Cisco IOS XE 16.9.2 or later |
| Dimensions & Weight | |
| Width | 44.5 cm |
| Depth | 4.4 cm |
| Height | 35 cm |
| Weight | 5.5 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - advance parts replacement - lifetime - response time: next business day Technical support - phone consulting - 90 days |
| Environmental Parameters | |
| Min Operating Temperature | -5 °C |
| Max Operating Temperature | 45 °C |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
