Сървър HPE ProLiant DL360 Gen11, Intel Xeon Silver 4509Y 8C (2.6/4.1 GHz, 22.5MB Cache), 32GB DDR5, без HDD 8x 2.5” SFF, RAID контролер MR408i-o, 4x 1GbE, 1000W PSU, Free DOS

SKU: P70540-421

ID: #41223

Характеристики

Серия: ProLiant DL360 Gen11

Чипсет: Intel C741

Процесор, серия: Intel Xeon Silver (8-ядрен)

Процесор: Intel Xeon Silver 4509Y 8C (2.6/4.1 GHz, 22.5MB Cache)

Брой процесори: 1

Поддържани процесори: 2

Памет, GB: 32GB DDR5 5600MHz

Памет, слотове: 32 (Общо) / 31 (празно)

Максимална памет, GB: 4TB DIMM

Брой поддържани дискове: до 8 x 2.5” LFF

Поддръжка на RAID: RAID 0, RAID 1, RAID 5, RAID 10, RAID 50, RAID 60

Оптично устройство: Не

Видео интерфейс: VGA

Мрежа: 4 x Gigabit Ethernet

Мощност на захранващ блок (W): 1000 W

Форм-фактор: 1U Rack

Софтуер: Free DOS

Гаранция (месеца): 36

Направи запитване

Количество: бр.

Доставка до адрес:

Имена:

E-mail:

Телефон:

Съгласие за обработване на личните ми данни за целите на директния маркетинг.

Добави за сравнение

Описание

HPE ProLiant DL360 Gen11 4509Y 2.6GHz 8-core 1P 32GB-R MR408i-o NC 8SFF 1000W PS Server


Manufacturer	HEWLETT PACKARD ENTERPRISE
Manufacturer Part No	P70540-421

Marketing Description
Do you need to efficiently expand or refresh your IT infrastructure to propel the business? Adaptable for diverse workloads and environments, the compact 1U HPE ProLiant DL360 Gen11 delivers enhanced performance with the right balance of expandability and density. Designed for supreme versatility and resiliency, the HPE ProLiant DL360 Gen11 is ideal for IT infrastructure, either physical, virtual, or containerized. The HPE ProLiant DL360 Gen11 supports the Intel Xeon, plus 4800 MT/s HPE DDR5 SmartMemory. Introducing PCIe Gen5 and Intel Software Guard Extensions (SGX) support on the dual-socket segment, the HPE ProLiant DL360 Gen11 complements Gen10 Plus reach by delivering premium compute, memory, networking communication, discrete graphic, I/O, and security capabilities for customers focused on performance at any cost. DL360 Gen11 server is an execellent choice of daily business and workloads in General Compute, Database Management, Virtual Desktop Infrastructure, Content Delivery Network, Edge Acceleration and Intelligent Video Analytics.
Product Features
Energy-efficient design Certified by ENERGY STAR, this server exemplifies efficiency in operation, reducing power consumption and lowering operational costs. Advanced connectivity Equipped with a variety of interfaces including USB 3.2 Gen 1, VGA, and HPE iLO for comprehensive connectivity options, ensuring seamless integration into any IT environment. Robust security features Comes with a suite of security standards including FIPS 140-2 and TLS v1.2, providing a secure foundation for your data and ensuring compliance with regulations. High-performance processing Powered by an Intel Xeon Silver processor with the capability to scale up to 2 processors, offering robust performance for demanding applications. Flexible storage solutions Features hot-swap server storage bays, allowing for easy maintenance and upgrades without system downtime, ensuring continuous operation.
General
Type	Server
Product Form Factor	Rack-mountable - 1U
Built-in Devices	Led panel
Embedded Security	Trusted Platform Module (TPM) Security Chip
Server Scalability	2-way
Hot-Swap Bays Qty	8
Localisation	Region: EMEA
Processor / Chipset
CPU	Intel Xeon Silver 4509Y
Clock Speed	2.6 GHz
Max Turbo Speed	4.1 GHz
Number of Cores	8-core
CPU Qty	1
Max CPU Qty	2
CPU Upgradability	Upgradable
Chipset Type	Intel C741
Cache Memory
Installed Size	22.5 MB
Cache Per Processor	22.5 MB
RAM
Installed Size	32 GB (installed) / 4 TB (max)
Technology	DDR5 SDRAM - Advanced ECC
Effective Memory Speed	4400 MHz
Rated Memory Speed	5600 MHz
Form Factor	DIMM 288-pin
Slots	32 (Total) / 31 (empty)
Features	Registered, slots 17 - 32 are available in two-processor configuration only, HPE SmartMemory
Configuration Features	1 x 32 GB
Hard Drive
Type	No HDD
Storage Controller
Type	1 x RAID - OCP
Controller Interface Type	Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name	HPE MR408i-o Gen11 SPDM
Channel Qty	8
Buffer Size	4 GB
Optical Storage
Type	No optical drive
Monitor
Monitor Type	None.
Graphics Controller
Video Memory	16 MB
Video Interfaces	VGA
Networking
Interface (Bus) Type	Open Compute Project mezzanine (OCP) 3.0
Ethernet Ports	4 x Gigabit Ethernet
Ethernet Controller	Broadcom BCM5719
Data Link Protocol	Gigabit Ethernet, Ethernet, Fast Ethernet
Remote Management Protocol	SNMP 3, SMASH CLP, IPMI 2.0
Remote Management Controller	Integrated Lights-Out 6
Features	PXE support, Wake on LAN (WoL)
Expansion / Connectivity
Bays	1 (total) / 1 (free) x external Universal Media Bay 8 (total) / 8 (free) x hot-swap 2.5"
Slots	2 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode)
Interfaces	1 x HPE iLO - Type A (1 in front) 1 x HPE iLO - RJ-45 4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 internal) 1 x VGA 4 x LAN (Gigabit Ethernet) 1 x USB 2.0
Miscellaneous
Included Accessories	5 x standard fans, HPE Easy Install Rails
Compliant Standards	ASHRAE Class A3, ASHRAE Class A4, TLS v1.2, AES, FIPS 140-2, IPv6 Ready, PCI DSS, WEEE 2002/95/EC, ACPI 6.4, ErP Lot 9
Power
Device Type	Power supply - hot-plug
Power Redundancy	Optional
Power Redundancy Scheme	1+1 (with optional power supply)
Installed Qty	1
Max Supported Qty	2
Voltage Required	AC 100-240 V
Power Provided	1000 Watt
80 PLUS Certification	80 PLUS Titanium
Operating System / Software
OS Provided	No operating system
Software	HPE Server UEFI
Sustainability Information
ENERGY STAR Certified	Yes
ENERGY STAR Version	3.0
Manufacturer Warranty
Service & Support	Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Width	43.46 cm
Depth	75.31 cm
Height	4.29 cm
Weight	14.56 kg
Environmental Parameters
Min Operating Temperature	10 °C
Max Operating Temperature	35 °C
Humidity Range Operating	8 - 90% RH (non-condensing)

Technical data provided by third party. We assume no liability for errors within these data.
