Сървър HPE ProLiant DL160 Gen10 1HE Xeon-S 4210R 10-Core 2.4GHz, 1x16GB-R, 8xSFF, Hot Plug S100i, 500W, P35516-B21

SKU: 4034873

ID: #27060

Характеристики

Серия: ProLiant DL160

Чипсет: Intel C622

Процесор, серия: Intel Xeon Scalable (10-ядрен)

Процесор: Intel Xeon Scalable 4210R (10 core, 2.4 GHz, 13.75 MB, 100W)

Брой процесори: 1

Поддържани процесори: 2

Памет, GB: 16GB DDR4 2933MHz

Памет, слотове: 16 (Общо) / 15 (празно)

Максимална памет, GB: up to 1 TB

Твърд диск, GB: Няма

Поддръжка на RAID: SATA RAID 0, 1, 5, 10

Мрежа: 2 x Gigabit Ethernet

Мощност на захранващ блок (W): 500W 80 PLUS Platinum

Форм-фактор: 1U Rack

Гаранция (месеца): 36

Направи запитване

Количество: бр.

Доставка до адрес:

Имена:

E-mail:

Телефон:

Съгласие за обработване на личните ми данни за целите на директния маркетинг.

Добави за сравнение

Описание

HPE ProLiant DL160 Gen10 1HE Xeon-S 4210R 10-Core 2.4GHz 1x16GB-R 8xSFF Hot Plug S100i 500W Server


Manufacturer	HEWLETT PACKARD ENTERPRISE
Manufacturer Part No	P35516-B21

General
Type	Server
Product Form Factor	Rack-mountable - 1U
Server Scalability	2-way
Hot-Swap Bays Qty	8
Processor / Chipset
CPU	Intel Xeon Silver 4210R
Clock Speed	2.4 GHz
Max Turbo Speed	3.2 GHz
Number of Cores	10-core
CPU Qty	1
Max CPU Qty	2
CPU Upgradability	Upgradable
Chipset Type	Intel C622
Cache Memory
Installed Size	L3 Cache - 13.75 MB
Cache Per Processor	13.75 MB
RAM
Installed Size	16 GB / 1 TB (max)
Technology	DDR4 SDRAM - Advanced ECC
Effective Memory Speed	2400 MHz
Rated Memory Speed	2933 MHz
Form Factor	DIMM 288-pin
Slots	16 (Total) / 15 (empty)
Features	Registered, Online Spare Memory, HPE SmartMemory, 6-channel memory architecture
Configuration Features	1 x 16 GB
Hard Drive
Type	No HDD
Storage Controller
Type	1 x SATA - PCIe 3.0 x4
Controller Interface Type	SATA 6Gb/s
Storage Controller Name	HPE Smart Array S100i
Channel Qty	14
RAID Level	RAID 0, RAID 1, RAID 5, RAID 10
Optical Storage
Type	No optical drive
Monitor
Monitor Type	None.
Graphics Controller
Video Interfaces	VGA
Networking
Ethernet Ports	2 x Gigabit Ethernet
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol	SNMP 3, IPMI 2.0
Remote Management Controller	Integrated Lights-Out 5
Features	Wake on LAN (WoL), PXE support
Expansion / Connectivity
Bays	8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots	1 (total) / 1 (free) x microSD Card (internal) 1 (total) / 1 (free) x PCIe 3.0 x8 - low-profile 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height
Interfaces	1 x VGA 2 x LAN (Gigabit Ethernet) 1 x HPE iLO 1 x HPE iLO - RJ-45 4 x USB 3.0 (1 front, 2 rear, 1 internal)
Miscellaneous
Compliant Standards	WEEE, ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1
Power
Device Type	Power supply - hot-plug
Power Redundancy	Optional
Power Redundancy Scheme	1+1 (with optional power supply)
Installed Qty	1
Max Supported Qty	2
Voltage Required	AC 120/230 V (50/60 Hz)
Power Provided	500 Watt
80 PLUS Certification	80 PLUS Platinum
Operating System / Software
OS Certified	Microsoft Windows Server 2016, Microsoft Windows Server 2019, VMware ESXi 6.5 update 3, VMware ESXi 6.7 update 3, Red Hat Enterprise Linux 7.6, SuSE Linux Enterprise Server 12 SP4, SUSE Linux Enterprise Server 15 SP1
Environmental Standards
ENERGY STAR Certified	Yes
ENERGY STAR Version	2.1
Manufacturer Warranty
Service & Support	Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Width	43.46 cm
Depth	61.49 cm
Height	4.29 cm
Weight	10.97 kg
Environmental Parameters
Min Operating Temperature	10 °C
Max Operating Temperature	35 °C
Humidity Range Operating	8 - 90% (non-condensing)
Sound Emission	27.8 dBA
