Сървър Fujitsu Primergy RX2530 M6, Ice Lake Intel Xeon Gold 5317 3.0/3.6 GHz, 16GB DDR4 ECC, без твърд диск, 4x Gigabit Ethernet, 5x USB 3.0, 2x 900W PSU 80 PLUS Platinum, VFY:R2536SC050IN

SKU: 4489310

ID: #27061

Характеристики

Серия: Primergy RX2530 M6

Чипсет: Intel C621A

Процесор, серия: Intel Xeon Gold (12-ядрен)

Процесор: Intel Xeon Gold 5317, 3.0 GHz, 12C/24T, 18MB Cache, 150 W

Брой процесори: 1

Поддържани процесори: 2

Памет, GB: 16GB DDR4 3200MHz

Памет, слотове: 32 (Общо) / 31 (празно)

Максимална памет, GB: 10 TB (max)

Твърд диск, GB: Няма

Мрежа: 4 x Gigabit Ethernet

Мощност на захранващ блок (W): 900W 80 PLUS Platinum

Форм-фактор: 1U Rack

Софтуер: Не

Гаранция (месеца): 36

Направи запитване

Количество: бр.

Доставка до адрес:

Имена:

E-mail:

Телефон:

Съгласие за обработване на личните ми данни за целите на директния маркетинг.

Добави за сравнение

Описание

FUJITSU PY RX2530 M6 8x2.5inch Intel Xeon Gold 5317 16GB RG 3200 1R PLAN CP 4X1GB RACK MOUNT iRMC adv.


Manufacturer	FUJITSU TECHNOLOGY SOLUTIONS
Manufacturer Part No	VFY:R2536SC050IN

Marketing Description
The Fujitsu PRIMERGY RX2530 M6 server is a 2-socket platform providing the ideal balance of density and scalability. It is powered by an Intel Xeon processor in a dense 1U form factor. The system incredibly large amount of memory capacity provided by 32 DIMM slots (up to 10 TB of memory). Beside the enhanced DDR4 modules, it is also possible to combine them with Intel Optane persistent memory 200 series that provide fast, high-capacity and cost-effective memory for memory intensive workloads such as data analytics and in-memory databases.
Product Features
Optimized performance and density Ideal dual-socket platform for dense scale-out data center computing powered by Intel Xeon processors with up to 40 cores per CPU. Power your applications Combine performance and versatility to adapt to a variety of applications and meet future demands with 32 DIMM modules (16 of which can be PMem) and up to 10 TB of memory. Intel Optane persistent memory provide fast, high capacity and cost effective memory for memory intensive workloads. Easy expandability Benefit from the flexibility of 2.5", 3.5" as well as EDSFF storage drives for highest storage capacities with up to 32 drives per height unit (U) and additional expandability with up to 4 PCIe Gen4 slots flexible DynamicLoM adapters via OCP V3. Comprehensive protection Benefit from advanced security technologies such as Platform Firmware Resilience (PFR) to protect the most sensitive portions of a workload, encryption support to enhance data and VM protection as well as physical protection to avoid unauthorized access.
General
Type	Server
Product Form Factor	Rack-mountable - 1U
Server Scalability	2-way
Front Accessible Bays Qty	1
Hot-Swap Bays Qty	8
Localisation	Region: Europe
Processor / Chipset
CPU	Intel Xeon Gold 5317
Clock Speed	3 GHz
Max Turbo Speed	3.6 GHz
Number of Cores	12-core
CPU Qty	1
Max CPU Qty	2
CPU Upgradability	Upgradable
Chipset Type	Intel C621A
Cache Memory
Installed Size	18 MB
Cache Per Processor	18 MB
RAM
Installed Size	16 GB / 10 TB (max)
Technology	DDR4 SDRAM - ECC
Effective Memory Speed	2933 MHz
Rated Memory Speed	3200 MHz
Slots	32 (Total) / 31 (empty)
Features	Single rank, Memory Mirroring, Independent Memory Mode, slots 17 - 32 are available in two-processor configuration only, memory scrubbing, Single Device Data Correction (SDDC), Adaptive Double-Device Data Correction (ADDDC)
Configuration Features	1 x 16 GB
Hard Drive
Type	No HDD
Storage Controller
Type	1 x SATA
Controller Interface Type	SATA 6Gb/s
Channel Qty	10
Optical Storage
Type	No optical drive
Monitor
Monitor Type	None.
Graphics Controller
Video Interfaces	VGA
Networking
Ethernet Ports	4 x Gigabit Ethernet
Ethernet Controller	Intel I350-T4
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol	IPMI 2.0
Remote Management Controller	Integrated Remote Management Controller (iRMC S5)
Features	PXE support
Compliant Standards	OCP 3.0
Expansion / Connectivity
Bays	8 (total) / 8 (free) x hot-swap 2.5" SFF 1 (total) / 1 (free) x external 5.25" (9.5mm height)
Slots	1 PCIe 4.0 x8 - low-profile 2 PCIe 4.0 x16 - low-profile 1 PCIe 4.0 x16 - low-profile (2 processors must be installed)
Interfaces	5 x USB 3.0 (2 front, 2 rear, 1 internal) 1 x VGA 1 x management - RJ-45 4 x LAN (Gigabit Ethernet)
Miscellaneous
Included Accessories	Rack mounting kit
Cables Included	No power cord is included
Compliant Standards	FCC Class A certified, BSMI, GS, CB, CCC, ICES-003 Class A, RoHS, WEEE, KC, VCCI Class A, JIS C 61000-3-2, EAC, NMB-3 Class A, RCM, BIS
Power
Device Type	Power supply - hot-plug
Power Redundancy	Yes
Power Redundancy Scheme	1+1
Installed Qty	2
Max Supported Qty	2
Voltage Required	AC 100-240 V (50/60 Hz)
Power Provided	900 Watt
80 PLUS Certification	80 PLUS Platinum
Efficiency	94%
Operating System / Software
OS Provided	No operating system
Software	ServerView Embedded Lifecycle Management, iRMC S5 Advanced Pack
Manufacturer Warranty
Service & Support	Limited warranty - 3 years - on-site
Dimensions & Weight
Width	48.22 cm
Depth	80.745 cm
Height	4.27 cm
Weight	18.2 kg
Environmental Parameters
Humidity Range Operating	10 - 85% (non-condensing)
