Серия:
PRIMERGY RX2530 M6
Процесор:
Intel Xeon Gold 5317, 3.0 GHz, 12C/24T, 18MB Cache, 150 W
Памет, GB:
16GB RG 3200 1R
Памет, слотове:
32 (16 DIMMs per CPU, 8 channels with 2 slots per channel); DIMM (DDR4 RDIMM, LRDIMM and Intel Optane PMem); Memory capacity (min. - max.): 8 GB - 10 TB
Брой поддържани дискове:
8xSFF
Твърд диск, GB:
Няма
Оптично устройство:
Не
Съвместими операционни системи:
Windows Server 20162019/2022, Hyper-V Server 2016, Windows Storage Server 2016 Standard; VMware vSphere 7.0/6.7; SUSE Linux Enterprise Server 15/12; Red Hat Enterprise Linux 8/7; Oracle Linux 7
Разширителен слот:
PCI-Express 4.0 x8: 1 x Low profile; PCI-Express 4.0 x16: 3x Low profile (2nd processor required for slot 3); 1x16 if fh slot selected
Интерфейс:
5 x USB 3.0 (2x front, 2x rear, 1x internal); 2 x VGA; 1x optional (occupies PCIe slot)
Мрежа:
Dynamic LoM via OCP slot; OCPv3 compliant Optional OCP adaptor: 4 x 1 Gbit/s Ethernet (RJ45)
Порт за отдалечено управление:
1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s); Management LAN traffic can be switched to shared OCPv3 card, speed and connector is related to installed interface card.
Тип на шасито:
Hot-Plug
Форм-фактор:
1U Rack
Гаранция (месеца):
36
