Серия:
PowerEdge R540
Процесор:
Intel Xeon Silver 4210R 2.4G, 10C/20T, 9.6GT/s, 13.75M Cache, Turbo, HT (100W) DDR4-2400
Памет, GB:
32GB (2x16GB) RDIMM, 3200MT/s, Dual Rank
Памет, слотове:
16 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666 MT/s, 1TB* max
Брой поддържани дискове:
3.5" Chassis up to 8 Hot Plug HDs,PERC/
Твърд диск, GB:
2x600GB 10K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive, 3.5in HYB CARR
Оптично устройство:
No Internal Optical Drive
Съвместими операционни системи:
Canonical Ubuntu LTS, Citrix XenServer, Microsoft Windows Server with Hyper-V, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Разширителен слот:
PCIe Rear storage config: 1 x HH/HL (1U Left Riser) + 1 x HH/HL (1U Right risers) slot or 1 x HH/HL (1U Left Riser) + 1 x FH/HL (1U Right riser)
Интерфейс:
Front ports: Video, 1 x USB 2.0, dedicated IDRAC Direct USB, Rear ports: Video, serial, 2 x USB 3.0, dedicated iDRAC network port
Мрежа:
Single,Hot-plug Power Supply,495W
Порт за отдалечено управление:
iDrac9, Express
Тип на шасито:
Hot-Plug
Форм-фактор:
2U Rack
