| Marketing Description |
| Cisco 890 Series Integrated Services Routers (ISRs) are fixed-configuration routers that provide collaborative business solutions for secure voice and data communications to enterprise small branch offices. They are designed to deliver secure broadband, Metro Ethernet, wireless LAN (WLAN) connectivity, and business continuity. The routers also come with powerful management tools, such as the web-based Cisco Configuration Professional configuration management tool, which simplifies setup and deployment. Centralized management capabilities give network managers visibility and control of the network configurations at the remote site. |
| General |
| Device Type |
Router - 8-port switch (integrated) |
| Enclosure Type |
Desktop, rack-mountable - 1U |
| Connectivity Technology |
Wired |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Capacity |
IPSec VPN tunnels: 50 |
| Network / Transport Protocol |
L2TP, RSVP, ICMP/IP, IPSec, FTP, DHCP, DNS, L2TPv3, DDNS, RTP |
| Routing Protocol |
OSPF, RIP-1, RIP-2, BGP, EIGRP, HSRP, VRRP, NHRP, GRE, OSPFv3, policy-based routing (PBR), BGP-4+, WCCP, Bidirectional Forwarding Detection (BFD) |
| Remote Management Protocol |
Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI |
| Encryption Algorithm |
DES, Triple DES, SSL, PKI, 128-bit AES, 192-bit AES, 256-bit AES |
| Authentication Method |
RADIUS, TACACS+ |
| Features |
Firewall protection, NAT support, power over Ethernet (PoE), auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, dynamic DNS server, DiffServ support, MAC address filtering, IPv6 support, High Availability, Intrusion Prevention System (IPS), Low-latency queuing (LLQ), Class-Based Weighted Fair Queuing (CBWFQ), Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED), Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Quality of Service (QoS), Link Fragmentation and Interleaving (LFI), Dynamic Multipoint VPN (DMVPN), DHCP server, Virtual Route Forwarding-Lite (VRF-Lite), DNS proxy, fanless, DHCP relay, DHCP client, Class of Service (CoS), Flexible NetFlow (FNF), security lock slot (cable lock sold separately), DiffServ Code Point (DSCP) support, Storm Control |
| Compliant Standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.3af, IEEE 802.1x, CISPR 24, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, EN50082-1, EN 61000-6-1, KN22, EN 300386 |
| RAM |
512 MB (installed) / 1 GB (max) |
| Flash Memory |
256 MB |
| Communications |
| Type |
ISDN / analogue modem combo |
| Protocols & Specifications |
ITU V.92 |
| Expansion / Connectivity |
| Interfaces |
Management: 1 x console - RJ-45
USB 2.0: 1 x 4 pin USB Type A
LAN: 4 x 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45
LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45
WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45
WAN: 1 x SFP (mini-GBIC)
WAN: 1 x BRI ST
WAN: 1 x 10Base-T/100Base-TX - RJ-45
WAN: 1 x modem - RJ-11 |
| Power |
| Power Device |
External power adapter - 60 Watt |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Software / System Requirements |
| OS Provided |
Cisco IOS Advanced IP services |
| Dimensions & Weight |
| Width |
32.5 cm |
| Depth |
24.9 cm |
| Height |
4.4 cm |
| Weight |
2.5 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - advance parts replacement - 1 year - response time: 10 days |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
10 - 85% (non-condensing) |
