| Marketing Description |
| NETGEAR Smart S350 series consists of five switch models, including 8-, 24- and 48-port Gigabit Ethernet switches and 8-, and 24-port Gigabit Ethernet PoE+ switches with 2 or 4 SFP ports for fiber uplinks, offering powerful Layer 2 features, enhanced performance and ease of use. They are purposely designed for converged networks where voice, video, data are all carried on a single network platform. Advanced features such as L2/L3/L4 Access Control Lists (ACLs), Quality of Service (QoS), Link Aggregation Control Protocol (LACP) and Spanning Tree Protocol (STP) will ensure a high-speed and highly secured network environment for your business. |
| Product Features |
- Advanced VLAN support for better network segmentation
- L2/L3/L4 Access control lists (ACLs) for granular network access control including 802.1x port authentication
- QoS (Quality of Service) for traffic prioritization including port-based, 802.1p and L2/L3/L4 DSCP-based
- Auto “denial-of-service” (DoS) prevention
- Rate limiting and priority queuing for better bandwidth allocation
- Port mirroring for network monitoring
|
| General |
| Device Type |
Switch - 24 ports - smart |
| Enclosure Type |
Desktop, rack-mountable |
| Subtype |
Gigabit Ethernet |
| Ports |
24 x 10/100/1000 + 2 x SFP |
| Performance |
Switch fabric speed: 52 Gbps
Forwarding performance (64-byte packet size): 38.6 Mpps |
| Capacity |
ACL: 100
IGMP multicast groups: 512
Priority queues: 4
DHCP snooping entries: 8000 |
| MAC Address Table Size |
16K entries |
| Jumbo Frame Support |
9216 bytes |
| Routing Protocol |
IGMPv2, IGMP, IGMPv3 |
| Remote Management Protocol |
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP |
| Encryption Algorithm |
TLS |
| Authentication Method |
RADIUS, TACACS+ |
| Features |
VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), fanless, LACP support, DHCP client, 512KB packet buffer, dual firmware images, Strict Priority Queuing (SPQ), Class of Service (CoS), Strict Priority (SP), Type of Service (ToS), DiffServ Code Point (DSCP) support, cable test, rate limit, IGMP querier, Voice VLAN, VLAN management, Guest VLAN, Weighted Round Robin (WRR), MAC based VLAN, Auto VoIP, MAC lockdown, SNTP client |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3az |
| Processor |
: 800 MHz |
| RAM |
512 MB |
| Flash Memory |
128 MB |
| Status Indicators |
Power, link/activity, speed |
| Expansion / Connectivity |
| Interfaces |
24 x 1000Base-T RJ-45
2 x 1000Base-X SFP |
| Power |
| Power Device |
Internal power supply |
| Installed Qty |
1 |
| Power Consumption Operational |
13.5 Watt |
| Miscellaneous |
| Included Accessories |
Rubber feet |
| Rack Mounting Kit |
Included |
| MTBF |
1,999,947 hours |
| Compliant Standards |
BSMI CNS 13438 Class A, EN 60950, UL 1950, SCC, CNS 14336, EN 61000-3-3:2013, EN 55024:2010, YD/T993-1998, FCC CFR47 Part 15 A, GB 4943.1-2011, EN 55032:2012+AC:2013 Class A, ANSI C63.4-2014, AS/NZS 60950-1:2015, ICES-003:2016 issue 6 Class A, CISPR 32:2012, VCCI-CISPR 32:2016 Class A, AS/NZS CISPR32:2013 Class A, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 |
| Localisation |
Europe |
| Dimensions & Weight |
| Width |
32.8 cm |
| Depth |
16.9 cm |
| Height |
4.3 cm |
| Weight |
1.62 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 5 years
Limited warranty - replacement - 5 years - response time: next business day
Technical support - phone consulting - 90 days |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
45 °C |
| Humidity Range Operating |
95% (non-condensing) |
