| Marketing Description |
| Transform your classroom into a collaborative learning space with the BrightLink 695Wi ultra short-throw WXGA interactive display. Featuring 3,500 lumens of color and white brightness, the 695Wi delivers a dynamic, easy-to-read display up to 100" - from as close as 11" away. Turn almost any wall or existing whiteboard into an interactive workspace with touch-based interactivity - up to six users at once. |
| Product Features |
- Bright and colorful
It features 3500 lumens of color brightness (color light output) and 3500 lumens of white brightness (white light output).
- WXGA resolution
It has 1280 x 800 HD widescreen resolution.
- Interactive
Make almost any smooth, lightly-colored surface interactive with BrightLink solutions.
- Finger-touch enabled
Touch, draw, select and interact using intuitive and familiar gestures.
- Ultra-short throw projector
It's can be mounted only 11" away from the board for a projected image as large as 100" diagonal - with no shadow interference.
|
| General |
| Device Type |
3LCD projector - 720p |
| Built-in Devices |
Speaker |
| Networking |
Ethernet |
| Enclosure Colour |
Grey, white |
| Projector |
| Brightness (White) |
3500 lumens |
| Brightness (Colour) |
3500 lumens |
| Brightness (Reduced) |
2900 lumens |
| Contrast Ratio |
300:1 / 14000:1 (dynamic) |
| Image Size |
152 cm - 254 cm |
| Projection Distance |
0.4 m - 0.6 m |
| Throw Ratio |
0.28:1 |
| Digital Zoom Factor |
1.35x |
| Resolution |
WXGA - WXGA (1280 x 800) |
| Native Aspect Ratio |
16:10 |
| Colour Support |
1.07 billion colours |
| Bulb type |
250 Watt |
| Bulb life cycle |
Up to 5000 hour(s) - normal mode
Up to 10000 hour(s) - economic mode |
| Features |
sRGB colour profile, Blackboard Mode, EPSON 3LCD technology, Whiteboard Mode, Split Screen, Direct Power On, Direct Power Off, Automatic Brightness Adjustment, Dynamic Lamp Control, Dynamic Mode, Theater Mode |
| Lens |
| Focus Type |
Manual |
| Lens Aperture |
F/1.6 |
| Keystone Correction Direction |
Horizontal, vertical |
| Vertical Keystone Correction |
-3 / +3 |
| Horizontal Keystone Correction |
-3 / +3 |
| Video Input |
| Analogue video Signal |
RGB, composite video |
| Video Interfaces |
VGA, HDMI, composite video, MHL |
| LAN and Wireless Image Transferring Protocols |
Wired LAN |
| Speakers |
| Type |
Integrated |
| Sound Output Mode |
Mono |
| Output Power / Channel |
16 Watt |
| Speakers |
1 x mixed channel |
| Expansion / Connectivity |
| Interfaces |
1 x component video / RGB input - 15 pin HD D-Sub (HD-15)
1 x composite video input - RCA
1 x Mobile High-Definition Link (MHL) / HDMI
2 x HDMI input - 19 pin HDMI Type A
1 x USB 2.0 - 4 pin USB Type A
1 x USB 2.0 - 4 pin USB Type B
3 x audio line-in - mini-phone stereo 3.5 mm
1 x microphone
1 x audio line-out - mini-phone stereo 3.5 mm
1 x serial RS-232C - 9 pin D-Sub (DB-9)
1 x network - RJ-45
1 x VGA input / output - 15 pin HD D-Sub (HD-15)
1 x Sync in
1 x Sync out |
| Miscellaneous |
| Included Accessories |
Pen tray, wireless remote control, finger touch unit, interactive pens |
| Cables Included |
1 x USB cable |
| Mounting Kit |
Included |
| Security Features |
Security lock slot (cable lock sold separately), password protection |
| Environmental Standards |
| TCO Certified |
TCO Certified Projectors 8 |
| Power |
| Power Source |
AC |
| Voltage Required |
AC 230V (50 - 60 Hz) |
| Power Consumption Operational |
356 Watt |
| Power Consumption Stand by |
0.39 Watt |
| Software / System Requirements |
| Software Included |
Epson Easy Interactive Tools, EasyMP Monitor, EasyMP Multi PC Projection |
| Dimensions & Weight |
| Width |
36.7 cm |
| Depth |
40 cm |
| Height |
14.9 cm |
| Weight |
5.9 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 5 years - carry-in |
| Environmental Parameters |
| Min Operating Temperature |
5 °C |
| Max Operating Temperature |
35 °C |
| Humidity Range Operating |
20 - 80% |
| Sound Emission |
35 dBA |
| Sound Emission (Economic Mode) |
30 dBA |
