| Product Features |
- DLP technology
- Acer ColorBoost technology delivers vivid, lifelike images
- High brightness and contrast ratio
- Versatile display modes enable optimum performance in any situation
- Dynamic black/ExtremeEco functions help decrease lamp power
- Acer EcoProjection technology delivers intelligent power management
- Advanced keystone correction delivers optimum presentations
- Manual focus/zoom projection lens
- Digital zoom and pan move function
- Low input lag function helps reduce display input lag
- 1080p 120Hz supported
|
| General |
| Device Type |
DLP projector - 4K |
| 3D Capable |
Yes (3D glasses sold separately) |
| Projector |
| Microdisplay |
DMD Chip |
| Brightness |
4000 ANSI lumens |
| Brightness (Reduced) |
3200 ANSI lumens |
| Contrast Ratio |
10000:1 (dynamic) |
| Image Size |
69 cm - 762 cm |
| Projection Distance |
1.9 m - 9.7 m |
| Throw Ratio |
1.5 - 1.65:1 |
| Uniformity |
85 % |
| Resolution |
Ultra HD 4K - 3840 x 2160 |
| Native Aspect Ratio |
16:9 |
| Colour Support |
1.07 billion colours (30-bit) |
| Max Sync Rate (V x H) |
120 Hz |
| Bulb type |
UHP 240 Watt |
| Bulb life cycle |
Up to 4000 hour(s) - normal mode
Up to 10000 hour(s) - economic mode
Up to 15000 hour(s) - extreme economic mode |
| Features |
DLP 3D Ready, SmartFormat Technology, 24p True Cinema, ISFccc, 4:3 aspect ratio support, Acer ColorSafe II Technology, Rec. 709 Mode, High Dynamic Range (HDR), Football mode, Low Input Lag, Acer Bluelight Shield, auto shutdown, HDMI 3D ready, top-loading lamp, Wall-Color Compensation |
| Lens |
| Focus Type |
Manual |
| Lens Aperture |
F/2.0-2.05 |
| Zoom Type |
Manual |
| Zoom Factor |
1.1x |
| Keystone Correction Direction |
Horizontal, vertical |
| Vertical Keystone Correction |
-40 / +40 |
| Horizontal Keystone Correction |
-40 / +40 |
| Video Input |
| TV System |
NTSC, SECAM, PAL |
| Video Interfaces |
HDMI |
| Video Modes |
720p, 1080i, 1080p |
| Speakers |
| Type |
Integrated |
| Sound Output Mode |
Mono |
| Output Power / Channel |
3 Watt |
| Speakers |
1 x mixed channel |
| Expansion / Connectivity |
| Interfaces |
2 x HDMI - 19 pin HDMI Type A
1 x USB
1 x audio line-out
1 x serial RS-232 (management) |
| Miscellaneous |
| Included Accessories |
Carrying case, lens cover, remote control, battery for remote control, security card |
| Cables Included |
1 x HDMI cable - 1.8 m |
| Power |
| Power Source |
AC |
| Voltage Required |
AC 120/230 V |
| Power Consumption Operational |
245 Watt |
| Power Consumption Stand by |
0.5 Watt |
| Dimensions & Weight |
| Width |
33.2 cm |
| Depth |
22.5 cm |
| Height |
11 cm |
| Weight |
4 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 2 years - pick-up and return
Limited warranty - lamp - 1 year
Limited warranty - DLP chipset - 5 years |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
20 - 90% |
| Sound Emission |
33 dB |
| Sound Emission (Economic Mode) |
30 dB |
