Дънна платка Gigabyte B650M GAMING X AX, B650, AM5, DDR5, PCI-E 4.0, 4x SATA 6Gb/s, 2x M.2, 1x USB 3.2 Gen 2 Type-C, rev 1.3, mATX
изчерпан
Дънна платка Gigabyte B650M GAMING X AX, B650, AM5, DDR5, PCI-E 4.0, 4x SATA 6Gb/s, 2x M.2, 1x USB 3.2 Gen 2 Type-C, rev 1.3, mATX
Дънна платка Gigabyte B650M GAMING X AX, B650, AM5, DDR5, PCI-E 4.0, 4x SATA 6Gb/s, 2x M.2, 1x USB 3.2 Gen 2 Type-C, rev 1.3, mATX
Дънна платка Gigabyte B650M GAMING X AX, B650, AM5, DDR5, PCI-E 4.0, 4x SATA 6Gb/s, 2x M.2, 1x USB 3.2 Gen 2 Type-C, rev 1.3, mATX
Дънна платка Gigabyte B650M GAMING X AX, B650, AM5, DDR5, PCI-E 4.0, 4x SATA 6Gb/s, 2x M.2, 1x USB 3.2 Gen 2 Type-C, rev 1.3, mATX
Дънна платка Gigabyte B650M GAMING X AX, B650, AM5, DDR5, PCI-E 4.0, 4x SATA 6Gb/s, 2x M.2, 1x USB 3.2 Gen 2 Type-C, rev 1.3, mATX

Дънна платка Gigabyte B650M GAMING X AX, B650, AM5, DDR5, PCI-E 4.0, 4x SATA 6Gb/s, 2x M.2, 1x USB 3.2 Gen 2 Type-C, rev 1.3, mATX

SKU: B650M GAMING X AX
ID: #32476

Характеристики

Поддържани процесори: AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors
CPU Socket: AMD AM5
Чипсет: AMD B650
Максимален капацитет RAM памет: 4x DDR5, Maximum Memory Capacity 192GB
Поддръжка на Dualchannel: Да
Поддържана памет: DDR5
Поддръжка на RAID: RAID 0/1/10 for M.2 NVMe
HDMI: 1
DisplayPort: 2
Форм фактор: Micro ATX
Гаранция (месеца): 36

Направи запитване

Описание

  • CPU
    AMD Socket AM5, support for:
    AMD Ryzen™ 7000 Series Processors
    (Go to GIGABYTE's website for the latest CPU support list.)
  • Chipset
    AMD B650
  • Memory
    Support for DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800 MT/s memory modules
    4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory
    Dual channel memory architecture
    Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme
    Memory Profile (XMP) memory module
    (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.)
  • Onboard Graphics
    Integrated Graphics Processor with AMD Radeon™ Graphics support:
    - 2 x DisplayPorts, supporting a maximum resolution of 3840x2160@144 Hz

    * Support for DisplayPort 1.4 version


    - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

    * Support for HDMI 2.1 version and HDCP 2.3.
    ** Support for native HDMI 2.1 TMDS compatible ports


    (Graphics specifications may vary depending on CPU support.)
    Support for up to 3 displays at the same time
  • Audio
    Realtek® Audio CODEC
    High Definition Audio
    2/4/5.1/7.1-channel

    * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

  • LAN
    Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
  • Wireless Communication module
    Realtek® Wi-Fi 6E RTL8852CE
    - WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
    - BLUETOOTH 5.3
    - Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
    (Actual data rate may vary depending on environment and equipment.)
  • Expansion Slots
    CPU:
    - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)

    Chipset:
    - 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 (PCIEX1)
  • Storage Interface
    CPU:
    - 2 x M.2 connectors (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support)

    Chipset:
    - 4 x SATA 6Gb/s connectors
    RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
    RAID 0, RAID 1, and RAID 10 support for SATA storage devices
  • USB
    CPU:
    - 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support
    - 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel

    CPU + USB 2.0 Hub:
    - 4 x USB 2.0/1.1 ports on the back pane

    Chipset:
    - 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
    - 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
    - 4 x USB 2.0/1.1 ports available through the internal USB headers
  • Internal I/O Connectors
    1 x 24-pin ATX main power connector
    1 x 8-pin ATX 12V power connector
    1 x CPU fan header
    3 x system fan headers
    1 x addressable LED strip header (D_LED1)
    1 x addressable LED strip header (D_LED2)
    1 x RGB LED strip header
    2 x M.2 Socket 3 connectors
    4 x SATA 6Gb/s connectors
    1 x front panel header
    1 x front panel audio header
    1 x USB Type-C® header, with USB 3.2 Gen 2 support
    1 x USB 3.2 Gen 1 header
    2 x USB 2.0/1.1 headers
    1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 / GC-TPM2.0 SPI V2 module only)
    1 x serial port header
    1 x reset button
    1 x reset jumper
    1 x Clear CMOS jumper
  • Back Panel Connectors
    4 x USB 2.0/1.1 ports
    1 x PS/2 keyboard/mouse port
    2 x SMA antenna connectors (2T2R)
    2 x DisplayPorts
    1 x HDMI port
    1 x USB 3.2 Gen 2 Type-A port (red)
    1 x USB Type-C® port, with USB 3.2 Gen 2 support
    1 x Q-Flash Plus button
    1 x RJ-45 port
    2 x USB 3.2 Gen 1 ports
    3 x audio jacks
  • I/O Controller
    iTE® I/O Controller Chip
  • H/W Monitoring
    Voltage detection
    Temperature detection
    Fan speed detection
    Fan fail warning
    Fan speed control
    * Whether the fan speed control function is supported will depend on the fan you install.
  • BIOS
    1 x 256 Mbit flash
    Use of licensed AMI UEFI BIOS
    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
  • Unique Features
    Support for GIGABYTE Control Center (GCC)

    * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.


    Support for Q-Flash
    Support for Q-Flash Plus
  • Bundled Software
    Norton® Internet Security (OEM version)
    LAN bandwidth management software
  • Operating System
    Support for Windows 11 64-bit
    Support for Windows 10 64-bit
  • Form Factor
    Micro ATX Form Factor; 24.4cm x 24.4cm
