| General |
| Device Type |
DLP projector - 1080p |
| 3D Capable |
Yes (3D glasses sold separately) |
| Built-in Devices |
Speaker |
| Enclosure Colour |
White |
| Projector |
| Microdisplay |
DMD Chip |
| Brightness |
4500 ANSI lumens |
| Brightness (Reduced) |
3600 ANSI lumens |
| Contrast Ratio |
10000:1 (dynamic) |
| Projection Distance |
1 m - 9.7 m |
| Throw Ratio |
1.5 - 1.65:1 |
| Uniformity |
85 % |
| Digital Zoom Factor |
2x |
| Resolution |
WUXGA (1920 x 1200) |
| Native Aspect Ratio |
16:10 |
| Colour Support |
1.07 billion colours |
| Max Sync Rate (V x H) |
120 Hz x 100 kHz |
| Bulb type |
UHP 240 Watt |
| Bulb life cycle |
Up to 4000 hour(s) - normal mode
Up to 10000 hour(s) - economic mode
Up to 20000 hour(s) - extreme economic mode |
| Features |
DLP 3D Ready, SmartFormat Technology, 16:9 aspect ratio support, EcoProjection Technology, 24p True Cinema, 4:3 aspect ratio support, Acer ColorSafe II Technology, ColorBoost 3D Technology, Low Input Lag, Acer LumiSense, Acer Bluelight Shield, auto shutdown, HDMI Power On, HDMI 3D ready, top-loading lamp, Wall-Color Compensation |
| Lens |
| Lens Aperture |
F/2.0-2.05 |
| Zoom Factor |
1.1x |
| Keystone Correction Direction |
Vertical |
| Vertical Keystone Correction |
-40 / +40 |
| Video Input |
| Video Interfaces |
VGA, HDMI, composite video, MHL |
| Speakers |
| Type |
Integrated |
| Sound Output Mode |
Mono |
| Output Power / Channel |
10 Watt |
| Speakers |
1 x mixed channel |
| Expansion / Connectivity |
| Interfaces |
1 x HDMI - 19 pin HDMI Type A
2 x VGA input - 15 pin HD D-Sub (HD-15)
1 x Mobile High-Definition Link (MHL) / HDMI
1 x serial RS-232
1 x VGA output - 15 pin HD D-Sub (HD-15)
1 x composite video input - RCA
1 x audio line-in - mini-phone 3.5 mm
1 x audio line-out - mini-phone 3.5 mm
1 x USB - 4 pin USB Type A |
| Miscellaneous |
| Included Accessories |
Lens cover |
| Cables Included |
1 x VGA cable - 1.8 m |
| Security Features |
Security lock slot (cable lock sold separately) |
| Security Slot Type |
Kensington security slot |
| Power |
| Power Consumption Operational |
300 Watt |
| Power Consumption Stand by |
0.5 Watt |
| Dimensions & Weight |
| Width |
32.2 cm |
| Depth |
22.5 cm |
| Height |
9.1 cm |
| Weight |
2.6 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 2 years - pick-up and return
Limited warranty - lamp - 1 year
Limited warranty - DLP chipset - 5 years |
| Environmental Parameters |
| Sound Emission |
32 dB |
| Sound Emission (Economic Mode) |
26 dB |
