| General |
| Device Type |
DLP projector - 1080p |
| 3D Capable |
Yes (3D glasses sold separately) |
| Built-in Devices |
Speaker |
| Projector |
| Microdisplay |
DMD Chip |
| Brightness |
4500 ANSI lumens |
| Brightness (Reduced) |
3600 lumens |
| Contrast Ratio |
10000:1 (dynamic) |
| Image Size |
69 cm - 762 cm |
| Projection Distance |
1.9 m - 9.7 m |
| Throw Ratio |
1.127 - 1.46:1 |
| Uniformity |
85 % |
| Digital Zoom Factor |
2x |
| Resolution |
WUXGA - WUXGA (1920 x 1200) |
| Native Aspect Ratio |
16:10 |
| Colour Support |
1.07 billion colours (30-bit) |
| Max Sync Rate (V x H) |
120 Hz x 100 kHz |
| Bulb type |
240 Watt |
| Bulb life cycle |
Up to 4000 hour(s) - normal mode
Up to 10000 hour(s) - economic mode
Up to 20000 hour(s) - extreme economic mode |
| Controls & Adjustments |
Rotation, tilt |
| Features |
Picture in picture, DLP 3D Ready, Auto Vertical Keystone, ColorBoost Technology, SmartFormat Technology, 16:9 aspect ratio support, Wireless Ready, 24p True Cinema, 4:3 aspect ratio support, Acer ColorSafe II Technology, 360° projection, Low Input Lag, Acer LumiSense, Acer Bluelight Shield, auto shutdown, PIN security |
| Lens |
| Lens Aperture |
F/1.94-2.07 |
| Zoom Type |
Manual |
| Zoom Factor |
1.3x |
| Keystone Correction Direction |
Vertical |
| Vertical Keystone Correction |
-40 / +40 |
| Video Input |
| TV System |
NTSC, SECAM, PAL |
| Video Interfaces |
HDMI |
| Video Modes |
720p, 1080i, 1080p |
| Speakers |
| Type |
Integrated |
| Sound Output Mode |
Mono |
| Output Power / Channel |
10 Watt |
| Speakers |
1 x mixed channel |
| Expansion / Connectivity |
| Interfaces |
2 x HDMI - 19 pin HDMI Type A
2 x USB - 4 pin USB Type A
1 x audio line-in - mini-phone stereo 3.5 mm
1 x audio line-out - mini-phone mono 3.5 mm
1 x serial RS-232 (management) |
| Miscellaneous |
| Included Accessories |
Remote control, battery for remote control, security card |
| Compliant Standards |
ISO 21118, HDCP |
| Power |
| Power Source |
AC |
| Voltage Required |
AC 100-240 V (50/60 Hz) |
| Power Consumption Operational |
309 Watt |
| Power Consumption Stand by |
0.5 Watt |
| Dimensions & Weight |
| Width |
34.3 cm |
| Depth |
22.5 cm |
| Height |
11.2 cm |
| Weight |
3.7 kg |
| Dimensions & Weight (Shipping) |
| Shipping Width |
43.3 cm |
| Shipping Depth |
16.2 cm |
| Shipping Height |
29.7 cm |
| Shipping Weight |
4.3 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 3 years - pick-up and return
Limited warranty - lamp - 1 year
Limited warranty - DLP chipset - 5 years |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
20 - 90% RH |
| Sound Emission |
32 dB |
| Sound Emission (Economic Mode) |
27 dB |
