| Cybenetics Efficiency | Gold |
|---|---|
| Cybenetics Noise | A |
| ATX Connector | 1 |
| ATX12V Version | 3.1 |
| Cable Type | Type 4 |
| Continuous Power W | 1000 Watts |
| EPS Connector | 2 |
| MTBF Hours | 100,000 hours |
| SATA Connector | 12 |
| PATA Connector | 6 |
|---|---|
| Modern Standby | Yes |
| Dimensions | 160x150x86 |
| Modular | Fully |
| PCIe Connector | 4 |
| Zero RPM Mode | Yes |
| Weight | 3.65 |
Modular ATX Cable (24-pin)
Connectors per cable
1
Total connectors
1
Connector spacing
-
Total length
610mm
(± 10mm)
Cable type
Embossed
QTY
1
EPS / ATX 12V 8-pin (4+4)
Connectors per cable
1
Total connectors
2
Connector spacing
-
Total length
750mm
(± 10mm)
Cable type
Embossed
QTY
2
PCIe 12V-2x6-pin (12+4)
Connectors per cable
1
Total connectors
1
Connector spacing
-
Total length
650mm
(± 10mm)
Cable type
Embossed
QTY
1
PCIe 8-pin (6+2)
Connectors per cable
1
Total connectors
4
Connector spacing
-
Total length
650mm
(± 10mm)
Cable type
Embossed
QTY
4
SATA (4 Connectors)
Connectors per cable
4
Total connectors
12
Connector spacing
505mm,115mm,115mm,115mm
Total length
850mm
(± 10mm)
Cable type
Embossed
QTY
3
PATA (3 Connectors)
Connectors per cable
3
Total connectors
6
Connector spacing
550mm, 100mm, 100mm
Total length
750mm
(± 25mm)
Cable type
Embossed
QTY
2
