Захранване Asus ROG Thor Platinum II, 1000W, Active PFC, 80+ Platinum, PCIe Gen 5.0, 135mm вентилатор
изчерпан
Захранване Asus ROG Thor Platinum II, 1000W, Active PFC, 80+ Platinum, PCIe Gen 5.0, 135mm вентилатор

Захранване Asus ROG Thor Platinum II, 1000W, Active PFC, 80+ Platinum, PCIe Gen 5.0, 135mm вентилатор

SKU: 90YE00L4-B0NA00
ID: #34471

Характеристики

Мощност, W: 1000 W
Брой вентилатори: 1 x 135 mm
Модулен захранващ блок: Да
Ефективност: 92%
Сертификат: 80 PLUS® Platinum
Цвят: Black
Гаранция (месеца): 36

Направи запитване

Описание

ASUS ROG THOR 1000W Platinum II Fully Modular Power Supply 80 Plus Platinum ROG heatsinks 135mm PWM fan Aura Sync PCIe Gen 5.0 Ready

Manufacturer ASUS
Manufacturer Part No 90YE00L4-B0NA00

Marketing Description
Back with a vengeance, the second iteration of the ROG Thor 1000 W Platinum wields cooling and component upgrades that make it the quietest PSU in its class. And to compliment the latest high-end ROG motherboards and bring additional flair to beastly rigs, ASUS has added a mirrored side panel that neatly frames the OLED display.
Product Features
  • ROG heatsinks
    ROG heatsinks have 2x more volume than traditional designs, facilitating lower temperatures, longer component lifespan, and extended 0 dB operation.
  • Axial-tech fan design
    A 135 mm Axial-tech fan with PWM control delivers lower noise and keeps thermals in check.
  • Dual ball fan bearings
    The fan impeller spins on a dual ball bearing setup that will last up to twice as long as a sleeve bearing design.
  • 0 dB technology
    To reduce noise output, the PWM-controlled fan shuts off entirely when the PSU load is 50% or below.
  • Lambda A++ Certification
    Thor II cooling upgrades result in a coveted Lambda A++ noise rating, confirming the latest iteration wields menacing power in absolute stealth.
  • 80 Plus Platinum Certification
    The ROG Thor 1000 W Platinum II utilizes low-ESR Japanese capacitors to ensure efficient operation. These upgrades enable an 80 PLUS Platinum certification, which guarantees 89% efficiency at 100% load and 92% efficiency at 50% load. The increased efficiency results in less heat, reduces fan noise, and increases reliability.
  • OLED power display
    The built-in OLED panel makes it easy to tune your system for best performance and efficiency.
  • Aura Sync
    Customize the Aura ROG logo and/or add RGB lighting strips to accent your showcase build.
  • Sleeved cables
    A range of sleeved cables are bundled with Thor II, and ASUS also provides a 20% CableMod discount.
  • PCIe Gen 5.0 ready
    Each ROG Thor 1000 W Platinum II PSU is bundled with a 16-pin PCIe cable that can pipe up to 600 W of power to PCIe Gen 5.0 graphics cards. Get ready for the future of power delivery.
General
Device Type Power supply - internal
Specification Compliance ATX12V
PSU Form Factor ATX
Power Device
Input Voltage AC 100-240 V
Power Output Connectors Details 1 x power 24 pin ATX with detachable 4 pin section
1 x power 8 pin EPS12V with detachable 4 pin ATX12V section
1 x 12 pin PCI Express power
8 x 8 pin PCI Express power with detachable 2 pin section
12 x 15 pin Serial ATA power
Output Voltage +3.3, +5, ±12 V
Power Capacity 1000 Watt
Output Current +3.3V - 25 A
+5V - 25 A
+12V - 83 A
-12V - 0.3 A
+5VSB - 3 A
Efficiency 92%
Modular Cable Management Yes
80 PLUS Certification 80 PLUS Platinum
Miscellaneous
Included Accessories Screws, 12 cable ties, ROG sticker, 6 x ROG cable ties, cable combs
Cables Included AC input cable - external
Power 24 pin ATX with detachable 4 pin section modular cable 61 cm
2 x power 8 pin +12V with detachable 4 pin section modular cable 65 cm
16-pin 12VHPWR power cable 67.5 cm
4 x 8 pin PCI Express power with detachable 2 pin section modular cable 67.5 cm
2 x 2x 8 pin PCI Express power with detachable 2 pin section modular cable
3 x Serial ATA cable
ARGB sync cable
2 x 4 pin internal power cable
Cooling System 135 mm fan
Features Sleeved cables, over current protection, over voltage protection, overpower protection, undervoltage protection, short-circuit protection, dual ball bearing cooling fan, thermal protection, OLED display, fully modular, ASUS Aura Sync, ROG heatsink, Axial-tech fan design, 0db Technology, Lambda A++ Certification
Compliant Standards C-Tick, CB, CCC, FCC, RoHS, WEEE, TUV SUD, EAC
Manufacturer Warranty

Dimensions & Weight
Width 15 cm
Depth 19 cm
Height 8.6 cm
Weight 2.37 kg
Technical data provided by third party. We assume no liability for errors within these data.
