| Product Features |
- The quietest 1000W power supply
Back with a vengeance, the second iteration of the ROG Thor 1000W Platinum wields cooling and component upgrades that make it the quietest PSU in its class. And to compliment the latest high-end ROG motherboards and bring additional flair to beastly rigs, ASUS has added a mirrored side panel that neatly frames the OLED display.
- ROG heatsinks
ROG heatsinks have 2x more volume than traditional designs, facilitating lower temperatures, longer component lifespan, and extended 0dB operation.
- Axial-tech fan design
A 135mm Axial-tech fan with PWM control delivers lower noise and keeps thermals in check.
- Dual ball fan bearings
The fan impeller spins on a dual ball bearing setup that will last up to twice as long as a sleeve bearing design.
- 80 Plus Platinum certification
The ROG Thor 1000W Platinum II utilizes low-ESR Japanese capacitors to ensure efficient operation. These upgrades enable an 80 PLUS Platinum certification, which guarantees 89% efficiency at 100% load and 92% efficiency at 50% load. The increased efficiency results in less heat, reduces fan noise, and increases reliability.
- OLED power display
The built-in OLED panel makes it easy to tune your system for best performance and efficiency.
- Aura Sync
Customize the Aura ROG logo and/or add RGB lighting strips to accent your showcase build.
|
| General |
| Device Type |
Power supply - internal |
| Specification Compliance |
ATX12V |
| PSU Form Factor |
ATX |
| Power Device |
| Input Voltage |
AC 100-240 V |
| Power Output Connectors Details |
1 x power 24 pin ATX with detachable 4 pin section
2 x power 8 pin +12V with detachable 4 pin section
8 x 8 pin PCI Express power with detachable 2 pin section
12 x 15 pin Serial ATA power
6 x 4 PIN internal power
1 x 12 pin PCI Express power |
| Output Voltage |
+3.3, +5, ±12 V |
| Power Capacity |
1000 Watt |
| Output Current |
+3.3V - 25 A
+5V - 25 A
+12V - 83 A
-12V - 0.3 A
+5VSB - 3 A |
| Modular Cable Management |
Yes |
| 80 PLUS Certification |
80 PLUS Platinum |
| Miscellaneous |
| Included Accessories |
12 cable ties, ROG sticker, 6 x ROG cable ties |
| Cooling System |
135 mm fan |
| Features |
Over current protection, over voltage protection, overpower protection, undervoltage protection, short-circuit protection, dual ball bearing cooling fan, thermal protection, OLED display, fully modular, ASUS Aura Sync, ROG heatsink, Axial-tech fan design, 0db Technology, Lambda A++ Certification |
| Compliant Standards |
RoHS |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 10 years |
| Dimensions & Weight |
| Width |
15 cm |
| Depth |
19 cm |
| Height |
8.6 cm |
| Weight |
2.37 kg |
