| Marketing Description |
| Get amplified with the ZOTAC GAMING GeForce RTX 30 Series based on the NVIDIA Ampere architecture. Built with enhanced RT Cores and Tensor Cores, new streaming multiprocessors, and superfast GDDR6X memory, the ZOTAC GAMING GeForce RTX 3080 Trinity LHR 12GB gives rise to amplified gaming with ultra graphics fidelity. |
| Product Features |
- Dynamic RGB
SPECTRA 2.0 enables beautiful lighted colors and expressive animated options with powerful Addressable RGB LEDs. Set different lighting modes and colors for specific independent lighting zones, or as a synchronized whole. Tap into the ZOTAC GAMING Firestorm software to make the ZOTAC GAMING graphics card yours with just a few clicks.
- Bring down the mercury
A more refined IceStorm 2.0 cooling system is purpose-built for wider coverage to keep the GPU cooler and running stronger, with enhancements in the visible and in what lies underneath.
- Enhanced airflow
The ZOTAC GAMING graphics card enhances cooling performance by utilizing an 11-blade fan design. The curved blades optimized for static pressure can increase airflow by up to 10%.
- Active fan control
Users have more control over the fans when using the ZOTAC GAMING FireStorm software. Adjust fan rotations independently and apply increased airflow only to where and when it's needed.
- Wide and sectioned
A wide aluminum fin-stack array heatsink sectioned in up to three groups and paired with up to seven copper heat pipes, span the length of the graphics card to extract and distribute more heat more efficiently than before.
- Maximum contact
A new and improved heat pipe layout is utilized in a more densely packed space. The flattened and vertically-laid heatpipes add up to 72% more direct contact over the GPU to transfer heat efficiently and quickly away from the core.
- More resilient
The design of ZOTAC GAMING GeForce RTX 3080 12GB Series underlines durability from front to back with a full-board metal front plate and back plate to increase the overall card rigidity and structural integrity.
|
| General |
| Device Type |
Graphics card |
| Bus Type |
PCI Express 4.0 x16 |
| Graphics Engine |
NVIDIA GeForce RTX 3080 |
| Boost Clock |
1710 MHz |
| CUDA Cores |
8960 |
| VR Ready |
Yes |
| Max Resolution |
7680 x 4320 at 60 Hz |
| Max Monitors Supported |
4 |
| Interfaces |
3 x DisplayPort
HDMI |
| API Supported |
OpenGL 4.6, DirectX 12 Ultimate |
| Features |
3-slot Fan Cooler, metal wraparound backplate, Real-Time Ray Tracing, Active Fan Control, IceStorm 2.0, SPECTRA 2.0 Lighting System, Freeze Fan Stop, Nvidia DLSS, NVIDIA Ampere GPU technology, NVIDIA Reflex, LHR (Lite Hash Rate), 2nd gen Ray Tracing Cores, 3rd gen Tensor Cores, HDCP |
| Memory |
| Size |
12 GB |
| Technology |
GDDR6X SDRAM |
| Memory Speed |
19 Gbps |
| Bus Width |
384-bit |
| System Requirements |
| OS Required |
Windows 10 64-bit Edition, Windows 11 |
| Required Power Supply |
750 W |
| Additional Requirements |
2 x 8 pin PCI Express power connector |
| Miscellaneous |
| Power Consumption Operational |
350 Watt |
| Included Accessories |
2 x Dual 6-pin PCIe to 8-pin power adapter |
| Software Included |
ZOTAC FireStorm |
| Compliant Standards |
HDCP 2.3, DisplayPort 1.4a |
| Width |
6.3 cm |
| Depth |
31.78 cm |
| Height |
12.07 cm |
