| Marketing Description |
| Poly Studio X50 Video Bar delivers radical simplicity in a small and elegant package. Now you can huddle in smaller rooms and connect easy in conference rooms with whatever video collaboration software you use, including native Zoom Rooms. Experience full board-room quality audio, advanced camera capabilities, and wireless content sharing that you can fling your content onto in seconds, all miniaturized into one sleek bar. So, say good bye to pucks, cords, and cables. Ditch the PC to drive the meeting, since the Poly Video OS runs the show. Easy to install, easy to manage - and best of all, easy to use. The new Poly Studio X line of video bars puts the mojo back into meetings. |
| Product Features |
- Simple setup gets rooms up and running in no time
- No PCs required, with cloud service platform support built-in, including Zoom
- Control with a quick touch on the screen
- Easily manage from anywhere across your network
- Easily share content over wired or wireless connections
- Dual monitor support with a simple touch interface
- Feel connected with production-quality camera framing
- Smart speaker tracking to show your best face every time
- Life-like 4K UltraHD video to see every detail
- Be heard clearly with next generation microphone array
- Room filling audio with an innovative acoustic chamber design
- Block out distractions with machine learning audio algorithms
- Stereo speakers for immersive, room-filling sound
- Native support for Video-as-a-Service (VaaS) platforms without the need for a PC
- H.323 and SIP support for easy connection to any standards-based video solutions
|
| General |
| Device Type |
Video conferencing device |
| VoIP Protocols |
H.323, SIP |
| Voice Codecs |
G.711, G.722, G.728, G.729a, G.722.1, G.722.1c, AAC-LD, G.719 |
| Video Codecs |
H.264, H.265, H.239, H.264 High Profile |
| Security |
128 bit AES, 256 bit AES, TLS 1.0, TLS 1.1, TLS 1.2, H.235.6, FIPS 140-2 |
| Width |
76.2 cm |
| Depth |
10.2 cm |
| Height |
10.2 cm |
| Weight |
2.54 kg |
| Built-in Devices |
Stereo speakers, camera, 3 microphones |
| Localisation |
Europe |
| Video Input |
| Type |
Digital camera - integrated |
| Video Modes |
2160p |
| Optical Zoom |
5 |
| Features |
Auto tracking, auto-framing, 120° field of view, 2 preset positions, Miracast connectivity |
| Video Output |
| Max External Resolution |
3840 x 2160 |
| Supported Display Graphics |
XGA (1024x768), SXGA (1280x1024), SXGA+ (1400x1050), HDTV (1920x1080), WUXGA (1920 x 1200), HD (1280 x 720), WSXGA+ (1680 x 1050), 352x240, 176x144, UHD (3840 x 2160) |
| Digital Video Standard |
High-Definition Multimedia Interface (HDMI) |
| Audio Input |
| Type |
Three microphones - integrated |
| Audio Output |
| Type |
Speaker(s) |
| Sound Output Mode |
Stereo |
| Networking |
| Type |
Network adapter |
| Connectivity Technology |
Wireless, wired |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0 |
| Features |
OCSP support, auto-uplink (auto MDI/MDI-X), IPv6 support, MIMO technology, IPv4 support, Apple AirPlay, Polycom Lost Packet Recovery (LPR) technology, Simple Certificate Enrollment Protocol (SCEP) |
| Compliant Standards |
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0 |
| Expansion / Connectivity |
| Interfaces |
1 x audio / video - HDMI input - 19 pin HDMI Type A
2 x audio / video - HDMI output - 19 pin HDMI Type A
1 x SuperSpeed USB 3.0
1 x USB-C - 24 pin USB-C
1 x audio - line-In - mini-phone 3.5 mm
1 x audio - line-out - mini-phone 3.5 mm
1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 |
| Miscellaneous |
| Included Accessories |
Wall mount, cables |
| Software Certification |
Zoom Certified |
| Compliant Standards |
FIPS 140-2 |
| Power |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - parts and labour - 1 year |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
15 - 80% (non-condensing) |
