| Marketing Description |
| Get amplified with the ZOTAC GAMING GeForce RTX 30 Series based on the NVIDIA Ampere architecture. Built with enhanced RT Cores and Tensor Cores, streaming multiprocessors, and superfast GDDR6X memory, the ZOTAC GAMING GeForce RTX 3080 Trinity OC LHR 12GB gives rise to amplified gaming with ultra-graphics fidelity. |
| Product Features |
- Get amplified
Tap into the fine-tuned balance of cooling, acoustics and aesthetics of the ZOTAC GAMING GeForce RTX 3080 12GB Series to amplify your gaming experience.
- Boost performance with AI
NVIDIA DLSS massively increases performance, without sacrificing quality, by using cutting-edge AI.
- More immersive experiences
Ray Tracing enables the most realistic and immersive graphics, which runs fast thanks to 2nd gen RT Cores.
- A competitive advantage
NVIDIA Reflex technologies minimize system latency which improves aim prevision and reaction time.
- Unleash the aurora
Exclusive to the AMP Holo is the HoloBlack design embracing an iridescent holographic finish that exudes an aurora like glow. The design captivates your eyes with the RGB lighting underneath and even with the lights off, the HoloBlack design itself is a showcase.
- Dynamic RGB
SPECTRA 2.0 enables beautiful lighted colors and expressive animated options with powerful addressable RGB LEDs. Set different lighting modes and colors for specific independent lighting zones, or as a synchronized whole. Tap into the ZOTAC GAMING FireStorm software to make the ZOTAC GAMING graphics card yours with just a few clicks.
- Bring down the mercury
A more refined IceStorm 2.0 cooling system is purpose-built for wider coverage to keep the GPU cooler and running stronger, with enhancements in the visible and in what lies underneath.
- Thicker
Sitting at a 3-slot GPU, the overall heatsink thickness increases 10% for even more surface area and stronger heat dissipation.
- Critical component contact
Memory and VRM modules make contact with the heatsink via premium thermal pads for cooling beyond just the GPU.
- More resilient
The design of ZOTAC GAMING GeForce RTX 3080 12GB Series underlines durability from front to back with a full-board metal frontplate and backplate to increase the overall card rigidity and structural integrity. The AMP Extreme Holo features an additional retention mount to reinforce contact.
- Take control
With a simple and intuitive minimal interface, the ZOTAC GAMING FireStorm Utility provides simple tools to transform fine-tuning your GPU into a simple task. Monitor your GPU, control the fan speed, adjust the SPECTRA supported RGB lighting, and many more options.
|
| General |
| Device Type |
Graphics card |
| Bus Type |
PCI Express 4.0 x16 |
| Graphics Engine |
NVIDIA GeForce RTX 3080 |
| Boost Clock |
1725 MHz |
| CUDA Cores |
8960 |
| VR Ready |
Yes |
| Max Resolution |
7680 x 4320 at 60 Hz |
| Max Monitors Supported |
4 |
| Interfaces |
3 x DisplayPort
HDMI |
| API Supported |
OpenGL 4.6, DirectX 12 Ultimate, Vulkan 1.2 |
| Features |
3-slot Fan Cooler, metal wraparound backplate, Real-Time Ray Tracing, Active Fan Control, IceStorm 2.0, SPECTRA 2.0 Lighting System, Freeze Fan Stop, Nvidia DLSS, Nvidia Studio, NVIDIA Ampere GPU technology, NVIDIA Reflex, LHR (Lite Hash Rate), 2nd gen Ray Tracing Cores, 3rd gen Tensor Cores, HDCP |
| Memory |
| Size |
12 GB |
| Technology |
GDDR6X SDRAM |
| Memory Speed |
19 Gbps |
| Bus Width |
384-bit |
| System Requirements |
| OS Required |
Windows 10 64-bit Edition, Windows 11 |
| Required Power Supply |
750 W |
| Additional Requirements |
2 x 8 pin PCI Express power connector |
| Miscellaneous |
| Power Consumption Operational |
350 Watt |
| Included Accessories |
2 x Dual 6-pin PCIe to 8-pin power adapter |
| Software Included |
ZOTAC FireStorm |
| Compliant Standards |
HDCP 2.3, DisplayPort 1.4a |
| Width |
6.3 cm |
| Depth |
31.78 cm |
| Height |
12.07 cm |
| Shipping Width |
12 cm |
| Shipping Depth |
44 cm |
| Shipping Height |
28.2 cm |
