| Marketing Description |
| The PowerColor Red Devil RX 6900 XT Ultimate features a new design with triple fans, a 320mm cooler with seven heatpipes. And a large copper base directly touches on the GPU and assists VRAMs to provide ultra-efficient heat transfer and dissipation. It is also equipped with a state-of-the-art PCB design utilizing a 14+2 phase VRM with DrMOS, high-quality polymer capacitors, and three 8-pin PCI-E connectors that will power the PowerColor RX 6900 XT Red Devil Ultimate. |
| Product Features |
- Two ball bearing technology: 4x greater longevity
The cooling fan utilizes two-ball bearing technology, increasing the longevity of the fans by up to four times.
- Mute Fan Technology: silent gaming
Mute Fan Technology intelligently turns off the fan below 60℃, providing silent gaming during medium and low load while reducing power consumption.
- Vertical aluminum fin design
The vertical design and increased array of aluminum fins improve heat spread dramatically. With a massive array of fins, the copper heatpipes can collect heat and dissipate it with maximum efficiency.
- Reinforced back plate
The metal back plate is extremely rigid to strengthen the card to prevent PCB bending, and the hollow area allows heat release promptly to enhance airflow.
|
| General |
| Device Type |
Graphics card |
| Bus Type |
PCI Express 4.0 |
| Graphics Engine |
AMD Radeon RX 6900 XT |
| Boost Clock |
2425 MHz |
| Stream Processors |
5120 |
| VR Ready |
Yes |
| Max Resolution |
7680 x 4320 |
| Interfaces |
HDMI
3 x DisplayPort |
| API Supported |
OpenGL, DirectX 12, Vulkan, DirectX 12 Ultimate |
| Features |
Dual Bios, AMD CrossFireX Technology, AMD Stream technology, FreeSync Technology, DrMOS, Mute Fan Technology, Radeon Chill, RGB Lighting, Radeon VR Ready Premium, Radeon WattMan, variable rate shading (VRS), Triple Fan Design, Radeon Boost, Radeon Image Sharpening, Radeon Anti-Lag, AMD FidelityFx, LED illuminated ports, RDNA 2 Architecture, AMD Infinity Cache, AMD Smart Access Memory technology, DirectX Raytracing (DXR) |
| Memory |
| Size |
16 GB |
| Technology |
GDDR6 SDRAM |
| Memory Speed |
16 Gbps |
| Bus Width |
256-bit |
| System Requirements |
| Required Power Supply |
900 W |
| Additional Requirements |
3 x 8 pin PCI Express power connector |
| Miscellaneous |
| Included Accessories |
Red Devil sticker, Devil Card, graphics card holder, Devil Gallery Card |
| Cables Included |
ARGB sync cable |
| Compliant Standards |
DisplayPort 1.4 |
| Width |
6.2 cm |
| Depth |
32 cm |
| Height |
13.5 cm |
