GPU architecture NVIDIA Blackwell
NVIDIA® CUDA® Cores 24,064
Tensor Cores 5th Generation
Ray Tracing Cores 4th Generation
AI TOPS 4000 AI TOPS1,2
Single-precision performance 125 TFLOPS1
RT Core performance 380 TFLOPS1
GPU memory 96 GB GDDR7 with ECC
Memory interface 512-bit
Memory bandwidth 1792 GB/s
System interface PCIe 5.0 x16
Display connectors 4x DisplayPort 2.1b
Max simultaneous displays >4x 4096 x 2160 @ 120 Hz
>4x 5120 x 2880 @ 60 Hz
>2x 7680 x 4320 @ 60 Hz
Video Engines 4x NVENC (9th Gen)
4x NVDEC (6th Gen)
MIG Support >Up to 4x 24 GB
>Up to 2x 48 GB
>Up to 1x 96 GB
Power consumption Total board power: 600 W
Power connector 1x PCIe CEM5 16-pin
Thermal solution Double-flow-through
Form factor 5.4” H x 12” L, dual slot, extended height
Graphics APIs DirectX 12, Shader Model 6.6, OpenGL 4.63,
Vulkan 1.33
Compute APIs CUDA 12.8, OpenCL 3.0, DirectCompute
