| Marketing Description |
The WINDFORCE 2X cooling system features two unique blade fans, a composite copper heat pipe direct touch GPU and 3D active fan functionality, together delivering an effective heat dissipation capacity for higher performance at lower temperatures.
The graphics card uses the 4+2 power phase design to allow the MOSFET to operate at lower temperature, and over-temperature protection design and load balancing for each MOSFET, plus the Ultra Durable certified chokes and capacitors to provide excellent performance and longer system life.
The back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection. |
| Product Features |
- WINDFORCE 2X cooling system
The WINDFORCE 2X cooling system features two unique blade fans, a composite copper heat pipe direct touch GPU and 3D active fan functionality, together delivering an effective heat dissipation capacity for higher performance at lower temperatures.
- Extreme durability and overclocking
The graphics card uses the 4+2 power phase design to allow the MOSFET to operate at lower temperature, and over-temperature protection design and load balancing for each MOSFET, plus the Ultra Durable certified chokes and capacitors to provide excellent performance and longer system life.
- Protective back plate
The back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
|
| General |
| Device Type |
Graphics card |
| Bus Type |
PCI Express 3.0 x16 |
| Graphics Engine |
NVIDIA GeForce GTX 1660 |
| Core Clock |
1830 MHz |
| CUDA Cores |
1408 |
| Max Resolution |
7680 x 4320 at 60 Hz |
| Max Resolution Details |
DisplayPort: 7680 x 4320 at 60 Hz/ HDMI: 4096 x 2160 at 60 Hz |
| Max Monitors Supported |
4 |
| Interfaces |
3 x DisplayPort
HDMI |
| API Supported |
DirectX 12, OpenGL 4.5 |
| Features |
Ultra Durable VGA, GIGABYTE WindForce 2x, NVIDIA G-Sync ready, NVIDIA G-Sync HDR ready |
| Memory |
| Size |
6 GB |
| Technology |
GDDR5 SDRAM |
| Effective Clock Speed |
8002 MHz |
| Bus Width |
192-bit |
| Bandwidth |
192 GBps |
| System Requirements |
| OS Required |
Microsoft Windows |
| Required Power Supply |
450 W |
| Additional Requirements |
8 pin PCI Express power connector |
| Miscellaneous |
| Software Included |
Display drivers |
| Compliant Standards |
DisplayPort 1.4 |
| Width |
4 cm |
| Depth |
22.4 cm |
| Height |
12.1 cm |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 3 years |
