Сървър Lenovo ThinkSystem ST50 V2, Intel Xeon E-2324G 4C (3.1/4.6GHz, 8MB Cache), 16GB DDR4 ECC, 1.92TB SSD, 1x 1GbE RJ45, 1x USB 3.2 Gen 2 Type-C, 2x DisplayPort, 500W PSU, Free DOS

SKU: 7D8JA043EA

ID: #41202

Характеристики

Серия: ThinkSystem ST50

Чипсет: Intel C256

Процесор, серия: Intel Xeon (4-ядрен)

Процесор: Intel Xeon E-2324G (4C/4T, 3.10 GHz, up to 4.5 GHz, 3,200 MHz)

Брой процесори: 1

Поддържани процесори: 1

Памет, GB: 16GB DDR4 3200MHz

Памет, слотове: 4 (Общо) / 3 (празно)

Максимална памет, GB: up to 128GB

Тип съхранение: 2.5" SSD / 3.5" HDD

Брой поддържани дискове: до 2 бр. 3.5” LFF

Капацитет SSD (GB): 2 x 960 GB

Поддръжка на RAID: SATA RAID 0, 1, 5, 10

Видео карта, модел: Intel UHD Graphics

Оптично устройство: Не

Видео интерфейс: 2 DisplayPort, 1 VGA

Мрежа: 1 x 10/100/1000 Mbps (RJ-45)

Мощност на захранващ блок (W): 500 W

Форм-фактор: 5U Tower

Софтуер: Free DOS

Гаранция (месеца): 36

Направи запитване

Количество: бр.

Доставка до адрес:

Имена:

E-mail:

Телефон:

Съгласие за обработване на личните ми данни за целите на директния маркетинг.

Добави за сравнение

Описание

LENOVO ThinkSystem ST50 V2 Xeon E-2324G 4C 3.1GHz 65W 1x16GB 3200MHz UDIMM 2x960GB 5400Pro SATA SSD SW RAID 1x500W PSU noDVD 3YR


Manufacturer	LENOVO
Manufacturer Part No	7D8JA043EA

General
Type	Server
Product Form Factor	Tower - 5U
Embedded Security	Trusted Platform Module (TPM 2.0) Security Chip
Server Scalability	1-way
Internal Bays Qty	2
Localisation	Region: EMEA
Processor / Chipset
CPU	Intel Xeon E-2324G
Clock Speed	3.1 GHz
Max Turbo Speed	4.6 GHz
Number of Cores	Quad-Core
CPU Qty	1
Max CPU Qty	1
CPU Socket	LGA1200 Socket
Chipset Type	Intel C256
Cache Memory
Installed Size	8 MB
Cache Per Processor	8 MB
RAM
Installed Size	16 GB / 128 GB (max)
Technology	DDR4 SDRAM - ECC
Effective Memory Speed	3200 MHz
Rated Memory Speed	3200 MHz
Form Factor	DIMM 288-pin
Slots	4 (Total) / 3 (empty)
Features	Unbuffered
Configuration Features	1 x 16 GB
Hard Drive
Type	SSD
Capacity	2 x 960 GB
Interface Type	SATA 6Gb/s
Storage Controller
Type	1 x SATA
Controller Interface Type	SATA 6Gb/s
Channel Qty	3
RAID Level	JBOD
Optical Storage
Type	No optical drive
Monitor
Monitor Type	None.
Graphics Controller
Graphics Processor	Intel UHD Graphics P750 Shared Video Memory (UMA)
Video Interfaces	DisplayPort
Networking
Ethernet Controller	Intel I219-LM
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Features	Wake on LAN (WoL), Teaming support, Intel Active Management Technology (AMT) 15
Compliant Standards	DASH 1.1
Expansion / Connectivity
Bays	1 (total) / 1 (free) x external 5.25" 2 (total) / 0 (free) x internal 3.5"
Slots	1 (total) / 1 (free) x PCIe 4.0 x16 - half-length, full-height 1 (total) / 1 (free) x PCIe 3.0 x1 - half-length, full-height 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height (x4 mode)
Interfaces	1 x USB-C 3.2 Gen 2 (1 in front) 2 x USB 3.2 Gen 2 (2 in front) 6 x USB 3.2 Gen 1 (2 front, 4 rear) 2 x DisplayPort 1 x LAN (Gigabit Ethernet) 1 x serial 1 x audio line-out 1 x VGA (on supplied cable)
Miscellaneous
Theft/Intrusion Protection	Security lock slot (cable lock sold separately), padlock loop
Security Slot Type	Kensington security slot
Compliant Standards	TUV GS, BSMI, IEC 60950-1, GB 17625.1, VCCI Class A, GB 4943.1, INMETRO, NOM-019, EK1-ITB2000, UL 2819, AS/NZS CISPR 32 Class A, KN32 Class A, EN 62368-1, IEC 62368-1, EN 55032 Class A, CISPR 32 Class A, TP TC 004/2011, HJ 2507-2011, Energy-Related Products (ErP) Lot 9, TP EAC 037/2016, ANSI/UL 62368-1, ICES-003 issue 7 Class A, GB/T9254, CQC3135, CSA C22.2 No. 62368-1, CMIM
Power
Device Type	Power supply
Voltage Required	AC 100-240 V (50/60 Hz)
Power Provided	500 Watt
80 PLUS Certification	80 PLUS Platinum
Efficiency	94%
Operating System / Software
OS Provided	No operating system
Manufacturer Warranty
Service & Support	Limited warranty - 3 years - on-site - response time: next business day
Dimensions & Weight
Width	17 cm
Depth	31.6 cm
Height	37.6 cm
Weight	9.4 kg
Dimensions & Weight (Shipping)
Shipping Width	28 cm
Shipping Depth	42 cm
Shipping Height	54 cm
Environmental Parameters
Min Operating Temperature	10 °C
Max Operating Temperature	35 °C
Humidity Range Operating	8 - 80%

Technical data provided by third party. We assume no liability for errors within these data.
