Сървър LENOVO ThinkSystem ST550 Xeon Silver 4208 8C 2.1GHz 11MB, 16GB 2933MHz RDIMM, без твърд диск 8x2.5in, SFF 930-8i 2GB, 2x1Gb, 1x750W XCC Ent No DVD, 7X10A0CWEA

SKU: 3843963

ID: #27056

Характеристики

Серия: ThinkSystem ST550

Процесор, серия: Intel Xeon Silver (8-ядрен)

Процесор: Intel Xeon Silver 4208 2.1GHz

Брой процесори: 1

Поддържани процесори: 2

Памет, GB: 16GB DDR4 2933MHz

Памет, слотове: 12 (Общо) / 11 (празно)

Максимална памет, GB: 768 GB (max)

Твърд диск, GB: Няма

Поддръжка на RAID: SATA RAID 0, 1, 5, 6, 10, 50, 60

Видео карта, модел: Matrox G200

Оптично устройство: Не

Мрежа: 2 x Gigabit Ethernet

Мощност на захранващ блок (W): 750W 80 PLUS

Форм-фактор: 4U Tower

Софтуер: Не

Гаранция (месеца): 36

Направи запитване

Количество: бр.

Доставка до адрес:

Имена:

E-mail:

Телефон:

Съгласие за обработване на личните ми данни за целите на директния маркетинг.

Добави за сравнение

Описание

LENOVO ThinkSystem ST550 Xeon Silver 4208 8C 2.1GHz 11MB 16GB 2933MHz RDIMM 8x2.5in SFF 930-8i 2GB 2x1Gb 1x750W XCC Ent No DVD


Manufacturer	LENOVO
Manufacturer Part No	7X10A0CWEA

Marketing Description
The Lenovo ThinkSystem ST550 2-socket 4U rack-mountable tower server provides outstanding performance and industry-leading reliability. It is ideal for small-to-medium businesses, distributed enterprises, retail, educational institutions and branch offices.
General
Type	Server
Product Form Factor	Tower - 4U
Embedded Security	Trusted Platform Module (TPM 1.2 and TPM 2.0)
Server Scalability	2-way
Hot-Swap Bays Qty	8
Localisation	Region: EMEA
Processor / Chipset
CPU	Intel Xeon Silver 4208
Clock Speed	2.1 GHz
Max Turbo Speed	3.2 GHz
Number of Cores	8-core
CPU Qty	1
Max CPU Qty	2
Processor Main Features	Hyper-Threading Technology, Intel Virtualization Technology, Intel Turbo Boost Technology 2
Cache Memory
Installed Size	L3 Cache - 11 MB
Cache Per Processor	11 MB
RAM
Installed Size	16 GB / 768 GB (max)
Technology	DDR4 SDRAM - ECC Chipkill
Effective Memory Speed	2400 MHz
Rated Memory Speed	2933 MHz
Form Factor	DIMM 288-pin
Slots	12 (Total) / 11 (empty)
Features	Registered, Memory Mirroring, Memory Sparing, mixing of different types of memory modules is not supported, slots 7 - 12 are available in two-processor configuration only
Configuration Features	1 x 16 GB
Hard Drive
Type	No HDD
Storage Controller
Type	1 x RAID - PCIe 3.0 x8
Controller Interface Type	SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name	ThinkSystem RAID 930-8i
Channel Qty	8
RAID Level	RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 60
Buffer Size	2 GB
Optical Storage
Type	No optical drive
Monitor
Monitor Type	None.
Graphics Controller
Graphics Processor	Matrox G200
Video Memory	16 MB
Video Interfaces	VGA
Networking
Ethernet Ports	2 x Gigabit Ethernet
Ethernet Controller	Intel X722
Data Link Protocol	Gigabit Ethernet
Remote Management Protocol	SNMP 3, CIM, IPMI 2.0
Remote Management Controller	XClarity Controller (XCC) Enterprise
Features	Wake on LAN (WoL)
Expansion / Connectivity
Bays	8 (total) / 8 (free) x hot-swap 2.5"
Slots	1 PCIe 3.0 x8 - half-length, full-height 1 PCIe 3.0 x16 - half-length, full-height 1 PCIe 3.0 x16 - full-length, full-height, double-width 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (x8 mode, 2 processors must be installed) 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height, double-width (2 processors must be installed) 1 PCIe 3.0 x8 - full-length, full-height
Interfaces	4 x USB 3.0 (1 front, 2 rear, 1 internal) 5 x USB 2.0 (1 front, 4 rear) 1 x VGA 1 x management - RJ-45 2 x LAN (Gigabit Ethernet)
Miscellaneous
Cables Included	Power cable
Theft/Intrusion Protection	Security lock slot (cable lock sold separately), chassis intrusion switch
Compliant Standards	TUV GS, BSMI, EN 61000-3-2, EN 61000-3-3, EN55024, CB, AS/NZS 60950-1, CCC, RoHS, IEC 60950-1, EN 60950-1, FCC Part 15 A, CSA C22.2 No. 60950-1, GB 17625.1, GB 9254 Class A, VCCI Class A, GB 4943.1, EK1-ITB2000, Energy-Related Products (ErP) Lot 3, CNS 13438 Class A, KN35, ICES-003 issue 6 Class A, AS/NZS CISPR 32 Class A, KN32 Class A, CNS 14336-1, EN 55032 Class A, CISPR 32 Class A, TR CU 020/2011, TR CU 004/2011, JESL, IEC/UL 60950-1, IEC 62368-1: 2014, CNS 15663
Power
Device Type	Power supply - hot-plug
Power Redundancy	Optional
Power Redundancy Scheme	1+1 (with optional power supply)
Installed Qty	1
Max Supported Qty	2
Voltage Required	AC 120/230 V (50/60 Hz)
Power Provided	750 Watt
80 PLUS Certification	80 PLUS Platinum
Operating System / Software
OS Provided	No operating system
Environmental Standards
ENERGY STAR Certified	Yes
ENERGY STAR Version	2.1
Manufacturer Warranty
Service & Support	Limited warranty - 3 years - on-site - response time: next business day
Dimensions & Weight
Width	17.58 cm
Depth	66.64 cm
Height	42.55 cm
Weight	36.9 kg
