Сървър Fujitsu RX1330M4 LFF, Intel Xeon E-2224 3.4/4.6 GHz, 16GB DDR4, без HDD, 2x 1GbE, 1x 450W, Free DOS, VFY:R1334SC340IN

SKU: 4056790

ID: #18958

Характеристики

Серия: RX1330M4

Чипсет: Intel C246

Процесор, серия: Intel Xeon (4-ядрен)

Процесор: Intel Xeon E-2224 3.4/4.6 GHz

Брой процесори: 1

Памет, GB: 16GB DDR4 2666MHz

Памет, слотове: DDR4 SDRAM - ECC / 4 (Общо) / 3 (празно)

Твърд диск, GB: Няма

Поддръжка на RAID: SATA RAID 0, 1, 10

Мрежа: 2x Gigabit Ethernet LAN

Мощност на захранващ блок (W): 450 W 80 PLUS

Форм-фактор: 1U Rack

Софтуер: Не

Гаранция (месеца): 12

Направи запитване

Количество: бр.

Доставка до адрес:

Имена:

E-mail:

Телефон:

Съгласие за обработване на личните ми данни за целите на директния маркетинг.

Добави за сравнение

Описание

FUJITSU RX1330M4 LFF HP PSU Xeon E-2224 16G RAM Rack Mount Kit iRMC advanced PSU 450W


Manufacturer	FUJITSU TECHNOLOGY SOLUTIONS
Manufacturer Part No	VFY:R1334SC340IN

Marketing Description
The PRIMERGY RX1330 M4 is a highly efficient and flexible single-socket rack server designed to deliver optimal performance and great value in a compact 1U. It provides versatile storage options with support for high-speed NVMe PCIe SSDs, making it ideal for applications that need higher I/O.
Product Features
Accelerate application performance Improve storage efficiency Maximize uptime and save energy cost
General
Type	Server
Product Form Factor	Rack-mountable - 1U
Server Scalability	1-way
Front Accessible Bays Qty	1
Hot-Swap Bays Qty	4
Processor / Chipset
CPU	Intel Xeon E-2224
Clock Speed	3.4 GHz
Max Turbo Speed	4.6 GHz
Number of Cores	Quad-Core
CPU Qty	1
Max CPU Qty	1
CPU Upgradability	Upgradable
CPU Socket	LGA1151 Socket
Chipset Type	Intel C246
Cache Memory
Installed Size	8 MB
Cache Per Processor	8 MB
RAM
Installed Size	16 GB / 64 GB (max)
Technology	DDR4 SDRAM - ECC
Effective Memory Speed	2666 MHz
Rated Memory Speed	2666 MHz
Slots	4 (Total) / 3 (empty)
Features	Unbuffered, dual channel memory architecture
Configuration Features	1 x 16 GB
Hard Drive
Type	No HDD
Storage Controller
Type	1 x SATA
Controller Interface Type	SATA 6Gb/s
Channel Qty	4
RAID Level	RAID 0, RAID 1, RAID 10
Optical Storage
Type	No optical drive
Monitor
Monitor Type	None.
Graphics Controller
Video Interfaces	VGA
Networking
Ethernet Ports	2 x Gigabit Ethernet
Ethernet Controller	Intel I210
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet, iSCSI
Remote Management Protocol	IPMI 2.0
Remote Management Controller	Integrated Remote Management Controller (iRMC S5)
Features	Wake on LAN (WoL), PXE support
Expansion / Connectivity
Bays	4 (total) / 2 (free) x hot-swap 3.5" 1 (total) / 1 (free) x external 5.25"
Slots	1 (total) / 1 (free) x PCIe 3.0 x4 - low-profile 2 (total) / 2 (free) x PCIe 3.0 x8 - low-profile 1 (total) / 1 (free) x PCIe 3.0 x8 (x4 mode) 2 (total) / 2 (free) x PCIe 3.0 x8
Interfaces	2 x USB 2.0 2 x USB 3.1 Gen 1 (2 in front) 2 x USB 3.1 Gen 2 1 x VGA 2 x LAN (Gigabit Ethernet) 1 x management - RJ-45
Miscellaneous
Compliant Standards	FCC Class A certified, C-Tick, BSMI, GOST, GS, CB, CCC, RoHS, WEEE, cULus, VCCI V-3, KC, cCSAus, JIS C 61000-3-2
Power
Device Type	Power supply - hot-plug
Power Redundancy	Yes
Power Redundancy Scheme	1+1 (with optional power supply)
Installed Qty	1
Max Supported Qty	2
Voltage Required	AC 120/230 V (50/60 Hz)
Power Provided	450 Watt
80 PLUS Certification	80 PLUS Platinum
Efficiency	94%
Operating System / Software
OS Provided	No operating system
Software	iRMC S5 Advanced Pack
Manufacturer Warranty
Service & Support	Limited warranty - 1 year - on-site
Dimensions & Weight
Width	48.26 cm
Depth	57.2 cm
Height	4.28 cm
Environmental Parameters
Min Operating Temperature	5 °C
Max Operating Temperature	45 °C
Humidity Range Operating	10 - 85% (non-condensing)
