Тип:
IP Recorder
Аудио компресия:
G.711ulaw/G.711alaw/G.722/G.726/AAC
Брой канали:
4 (IP Video Input)
HDMI:
1-ch, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz
VGA:
1-ch, 1920 x 1080/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz
Видео изходен режим:
HDMI1/VGA simultaneous output
Капацитет:
Incoming: 40 Mbps, Outgoing: 80 Mbps
Видео компресия:
H.265/H.265+/H.264+/H.264
Резолюция на запис:
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Дистанционна връзка:
128
Мрежови протоколи:
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
Мрежов интерфейс:
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Спомагателен интерфейс:
1x SATA interface (Up to 10 TB capacity for each HDD), Front panel: 1 Ч USB 2.0; Rear panel: 1 Ч USB 2.0
Захранване:
12 VDC, 1.5 A, Consumption: <= 10 W (without HDD)
Power Over Ethernet (PoE):
Не
Размери (Ш, Д, В), mm:
320 mm x 240 mm x 48 mm
Тегло, g:
<= 1 kg
Аудио:
1-ch, RCA (Linear, 1 kOhm); Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 kOhm, using the audio input)
Други:
AI By Device Facial recognition, perimeter protection, motion detection 2.0; AI By Camera Facial recognition, perimeter protection, throwing objects from building, motion detection2.0, ANPR, VCA; Motion Detection 2.0; Perimeter Protection
Гаранция (месеца):
24
