Тип:
Analog Recorder
Аудио компресия:
G.711u
Брой канали:
16-ch, BNC interface (1.0 Vp-p, 75 Ohm), supporting coaxitron connection, IP video input: 16-ch (up to 32-ch)
HDMI:
Out: 1-ch, 4K (3840 x 2160)/30Hz, 2K (2560 x 1440)/60Hz, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
VGA:
Out: 1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
Видео изходен режим:
Dual stream: Support, Stream type: Video, Video & Audio
Капацитет:
32 Kbps to 10 Mbps
Видео компресия:
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Резолюция на запис:
8 MP/5 MP/4 MP/ 3 MP/1080p/720p/WD1/4CIF/VGA/CIF
Дистанционна връзка:
128
Мрежови протоколи:
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
Мрежов интерфейс:
1x RJ45 10M/100M/1000M self-adaptive Ethernet interface
Спомагателен интерфейс:
2 SATA interfaces (Up to 10 TB capacity for each disk); Front panel: 1x USB 2.0, Rear panel: 1x USB 3.0
Захранване:
12 VDC; Consumption (without HDD): <=25 W
Power Over Ethernet (PoE):
Не
Размери (Ш, Д, В), mm:
380 x 320 x 48 mm
Тегло, g:
<= 2 kg
Аудио:
Audio input/Two-way audio: 1-ch, RCA (2.0 Vp-p, 1kOm); Out: 1-ch, RCA (Linear, 1 kOm)
Други:
Turbo HD/AHD/HDCVI/CVBS input
Гаранция (месеца):
24
