Тип:
Analog Recorder
Аудио компресия:
G.711u
Брой канали:
16-ch, BNC interface (1.0 Vp-p, 75 Ohm), supporting coaxitron connection; IP video input: 8-ch (up to 24-ch)
HDMI:
Out: 1-ch, 4K (3840 x 2160)/30Hz, 2K (2560 x 1440)/60Hz, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
VGA:
Out: 1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
Видео изходен режим:
Dual stream: Support; Stream type Video, Video & Audio
Капацитет:
32 Kbps to 4 Mbps
Видео компресия:
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Резолюция на запис:
When 4 MP Lite mode not enabled: 4 MP/4 MP Lite/3 MP/1080p/720p/WD1/4CIF/VGA/CIF; When 4 MP Lite mode enabled: 4 MP lite/3 MP/1080p lite/720p lite/WD1/4CIF/VGA/CIF
Дистанционна връзка:
128
Мрежови протоколи:
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Мрежов интерфейс:
1x RJ45 10M/100M/1000M self-adaptive Ethernet interface
Спомагателен интерфейс:
1 SATA interface (Up to 10 TB capacity for each disk); Rear panel: 2x USB 2.0
Захранване:
12 VDC; Consumption (without HDD): <=20W
Power Over Ethernet (PoE):
Не
Размери (Ш, Д, В), mm:
260 x 222 x 45 mm
Тегло, g:
<= 1.2 kg
Аудио:
Out: 1-ch, RCA (Linear, 1 kOm)
Други:
AHD/HDCVI/CVBSCVBS input
Гаранция (месеца):
24
