Тип:
Analog Recorder
Аудио компресия:
G.711u
Брой канали:
4-ch Analog video input, BNC interface (1.0 Vp-p, 75 Ohm), supporting coaxitron connection; IP video input: 1-ch (up to 5-ch)
HDMI:
Out: 1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
VGA:
Out: 1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
Видео изходен режим:
Dual stream: Support; Stream type: Video, Video & Audio
Капацитет:
32 Kbps to 4 Mbps
Видео компресия:
H.264+/H.264
Резолюция на запис:
When 1080p lite mode not enabled: 720p/WD1/4CIF/VGA/CIF, When 1080p lite mode enabled: 1080p lite/HD 720p lite/WD1/4CIF/VGA/CIF
Дистанционна връзка:
32
Мрежови протоколи:
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS, ONVIF
Мрежов интерфейс:
1x RJ45 10M/100M self-adaptive Ethernet interface
Спомагателен интерфейс:
1 SATA interface (Up to 6 TB capacity for each disk); Rear panel: 2x USB 2.0
Захранване:
12 VDC, 1.5 A; Consumption (without HDD): <=8 W
Power Over Ethernet (PoE):
Не
Размери (Ш, Д, В), mm:
260 x 222 x 45 mm
Тегло, g:
<= 0.8 kg
Аудио:
In: 1-ch, RCA (2.0 Vp-p, 1 kOm), 4-ch via coaxial cable; Out: 1-ch, RCA (Linear, 1 kOm); Two-way audio: Reuse the first audio input
Други:
Turbo HD/AHD/HDCVI input; CVBS input: Support
