Тип:
Hybrid Recorder
Аудио компресия:
G.711u
Брой канали:
Analog video input: 8-ch BNC interface; IP video input: 2-ch (up to 10-ch), Enhanced IP mode on: 4-ch (up to 12-ch), each)
HDMI:
Out: 1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
VGA:
Out: 1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
Видео изходен режим:
Dual stream: Support; Stream type: Video, Video & Audio
Капацитет:
Total: 96 Mbps; Incoming (Enhanced IP mode): 48 Mbps
Видео компресия:
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Резолюция на запис:
When 1080p Lite mode is not enabled: 4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF
Дистанционна връзка:
64
Мрежови протоколи:
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
Мрежов интерфейс:
1x RJ45 10M/100M self-adaptive Ethernet interface
Спомагателен интерфейс:
1 SATA interface (Up to 6 TB capacity for each disk), Real panel: 2x USB 2.0
Захранване:
12 VDC, 1.5 A; Consumption (without HDD): <= 12W
Power Over Ethernet (PoE):
Не
Размери (Ш, Д, В), mm:
200 x 200 x 45 mm
Тегло, g:
<= 1kg
Аудио:
In: 1-ch, RCA (2.0 Vp-p, 1 kOm), 8-ch via coaxial cable; Out: 1-ch, RCA (Linear, 1 kOm); Two-way audio 1-ch, RCA (2.0 Vp-p, 1 kOm) (using the first audio input)
Други:
HDTVI/AHD/HDCVI input; CVBS input: Support
Гаранция (месеца):
24
