Процесор Intel Core i7 12700 12C (2.1 / 4.9 GHz, 25MB Cache, 65W, LGA1700), BOX, с охлаждане

Intel® Core™ i7-12700 (25M Cache, up to 4.9 GHz)

Code Name: Products formerly Alder Lake
Vertical Segment: Desktop
Processor Number: i7-12700
Launch Date: Q1'22
Lithography: Intel 7 (10nm)
Use Conditions: PC/Client/Tablet

CPU Specifications

Total Cores: 12
# of Performance-cores: 8
# of Efficient-cores: 4
Total Threads: 20
Max Turbo Frequency: 4.90 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency: 4.90 GHz
Performance-core Max Turbo Frequency: 4.80 GHz
Efficient-core Max Turbo Frequency: 3.60 GHz
Performance-core Base Frequency: 2.10 GHz
Efficient-core Base Frequency: 1.60 GHz

Cache

25 MB Intel® Smart Cache
Total L2 Cache: 12 MB
Processor Base Power: 65 W
Maximum Turbo Power: 180 W

Max Memory Size (dependent on memory type) 128 GB

Memory Types
Up to DDR5: 4800 MT/s
Up to DDR4: 3200 MT/s
Max # of Memory Channels 2
Max Memory Bandwidth: 76.8 GB/s

Processor Graphics

Processor Graphics: Intel® UHD Graphics 770
Graphics Base Frequency: 300 MHz
Graphics Max Dynamic Frequency: 1.50 GHz
Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units: 32
Max Resolution (HDMI: 4096 x 2160 @ 60Hz
Max Resolution (DP: 7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel): 5120 x 3200 @ 120Hz
DirectX* Support: 12
OpenGL* Support: 4.5
Multi-Format Codec Engines: 2
Intel® Quick Sync Video: Yes
Intel® Clear Video HD Technology: Yes
# of Displays Supported: 4
Device ID: 0x4680
OpenCL* Support: 2.1

Expansion Options

Direct Media Interface (DMI) Revision 4.0
Max: of DMI Lanes 8
Scalability: 1S Only
PCI Express Revision: 5.0 and 4.0
PCI Express Configurations: Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes: 20

Package Specifications

Max CPU Configuration: 1
Thermal Solution Specification: PCG 2020C
TJUNCTION: 100°C
Package Size: 45.0 mm x 37.5 mm

Advanced Technologies

Intel® Gaussian & Neural Accelerator 3.0
Intel® Thread Director: Yes
Intel® Deep Learning Boost (Intel® DL Boost): Yes
Intel® Optane™ Memory Supported: Yes
Intel® Speed Shift Technology: Yes
Intel® Turbo Boost Max Technology 3.0: Yes
Intel® Turbo Boost Technology: 2.0
Intel® Hyper-Threading Technology: Yes
Intel® Virtualization Technology (VT-x): Yes
Intel® Virtualization Technology for Directed I/O (VT-d): Yes
Intel® VT-x with Extended Page Tables (EPT): Yes
Intel® 64: Yes
Instruction Set: 64-bit
Instruction Set: Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States: Yes
Enhanced Intel SpeedStep® Technology: Yes
Thermal Monitoring Technologies: Yes
Intel® Volume Management Device (VMD): Yes

Security & Reliability

Intel® AES New Instructions: Yes
Secure Key: Yes
Intel® OS Guard: Yes
Execute Disable Bit: Yes
Intel® Boot Guard: Yes
Mode-based Execute Control (MBE): Yes
Intel® Control-Flow Enforcement Technology: Yes
