Product Collection
Code Name
Vertical Segment
Desktop
Processor Number
i5-11400
Lithography
14 nm
Total Cores
6
Total Threads
12
Max Turbo Frequency
4.40 GHz
Intel® Turbo Boost Technology 2.0 Frequency‡
4.40 GHz
Processor Base Frequency
2.60 GHz
Cache
12 MB Intel® Smart Cache
Bus Speed
8 GT/s
TDP
65 W
Marketing Status
Discontinued
Launch Date
Q1'21
Embedded Options Available
No
Use Conditions
PC/Client/Tablet
Datasheet
Max Memory Size (dependent on memory type)
128 GB
Memory Types
DDR4-3200
Max # of Memory Channels
2
Max Memory Bandwidth
50 GB/s
ECC Memory Supported ‡
No
GPU Name‡
Intel® UHD Graphics 730
Graphics Base Frequency
350 MHz
Graphics Max Dynamic Frequency
1.30 GHz
Graphics Video Max Memory
64 GB
Execution Units
24
4K Support
Yes, at 60Hz
Max Resolution (HDMI)‡
4096x2160@60Hz
Max Resolution (DP)‡
5120 x 3200 @60Hz
Max Resolution (eDP - Integrated Flat Panel)‡
5120 x 3200 @60Hz
DirectX* Support
12.1
OpenGL* Support
4.5
OpenCL* Support
3.0
Intel® Quick Sync Video
Yes
Intel® InTru™ 3D Technology
Yes
Intel® Clear Video HD Technology
Yes
Intel® Clear Video Technology
Yes
# of Displays Supported ‡
3
Device ID
0x4C8B
Scalability
1S Only
PCI Express Revision
4.0
PCI Express Configurations ‡
Up to 1x16+1x4, 2x8+1x4, 1x8+3x4
Max # of PCI Express Lanes
20
Sockets Supported
FCLGA1200
Max CPU Configuration
1
Thermal Solution Specification
PCG 2019C
TJUNCTION
100°C
