Radiator Size 360 mm
Radiator Dimensions
(WxDxH) 394 x 119.2 x 27mm / 15.51 x 4.69 x 1.06 inches
Radiator Material Aluminum
Water Cooling Tube
Material Black Rubber
Number of Fans 3
Fan Dimensions
(WxDxH) 120 x 120 x 25mm / 4.7 x 4.7 x 0.98 inches
Fan Air Flow 25.5~75.04 CFM
Fan Bearing Fluid Dynamic Bearing (FDB)
Fan Life Expectancy 50,000 hrs@40℃
Fan Rated Current 0.25A(Max:0.4A)
Fan Power
Consumption 3W(Max:4.8W)
PWM Mode YES
Cable Length (PWM
Cable) 550 / 500 mm; 21.65 / 19.69 inches
Fan Connector 4-Pin
Fan Lighting ARGB
Pump Life Expectancy 200,000 hours in typical use
Pump Noise Level 20 dBA (avg.)
Pump Rated Current 0.25A (Max: 0.5A)
Pump Power
Consumption 3W (Max: 6W)
Pump Speed 3000 RPM ± 10%
Pump Connector 4-pin
Cold Plate Material Copper
Block Dimensions
(WxDxH) 74.9 x 65.4 x 54.2 mm
Intel Socket Support LGA 1150/1151/1155/1156/1200/1700/1851
AMD Socket Support AM5/AM4/TR4/sTRx4
Accessories
1 x 1 to 3 Fan PWM cable 1 x Molex 4-Pin to 4-Pin
fan cable 1 x low noise adapter cable 1 x Thermal
paste
