Host Connector |
1 - USB-C® Male |
Video Output |
1 - HDMI™ Female |
Power Source |
Bus-powered or self-powered |
Network Interface |
Yes |
Audio Supported |
Yes |
Ports |
|
Performance | |
Maximum Display Resolution |
3840 x 2160 |
Maximum Display Refresh Rate |
60 Hz |
Maximum Data Transfer Rate |
5 Gbps |
Maximum Displays Supported |
1 |
Compatible Networks |
10M/100M/1000M |
Audio Channel |
2.1 via HDMI™ |
Power | |
Power Delivery |
Up to 86W via USB-C® |
Power Consumption |
≤ 400 mA |
Input Current |
Up to 5A |
Input Voltage |
Up to 20V |
Output Current |
Up to 4.25A |
Output Voltage |
Up to 20V |
Physical Specifications | |
Color |
Silver |
Enclosure Type |
Aluminum |
Cable Length |
7.87 in. (200 mm) |
Product Height |
3.06 in. (77.6 mm) |
Product Width |
2.62 in. (66.5 mm) |
Product Depth |
0.58 in. (14.7 mm) |
Product Weight |
2.54 oz (72g) |
Storage Temperature |
0 to 155°F (-17 to 68°C) |
Storage Humidity |
< 85% non-condensing |
Operating Temperature |
32 to 118°F (0 to 48°C) |
Operating Humidity |
< 85% non-condensing |
