TAA Complaint
Yes
Panel Size (measured diagonally)
24” (23.8”)
Processor
Teradici Tera2321 PCoIP Chip
RAM
512MB
Protocol
PCoIP
Networking
10 / 100 / 1000
Color Depth
16.7M
Pixel Pitch(mm)
0.275(H) x 0.275(V) 0.2652 (H) x 0.2652 (V)
Contrast Ratio
1,000:1 (Typ) 5,000,000:1 (DFC)
Response Time (on/off)
14ms (GTG)
Viewing Angle (CR≥10)
178°/178°
Surface Treatment
Hard coating, Anti-Glare
Aspect Ratio
16:9
Brightness (Typ)
250 cd/m²
Color Depth (DFC)
16.7M
Panel Type
AH-IPS
Resolution
1,920 x 1,080
D-Sub
Yes
DVI
Yes
Others
10 / 100 / 1000
USB 2.0
6 (4 Back, 2 Side)
Mic In
Yes
Headphone Out
Yes
Networking
10/100/1000 Ethernet
Processor
Teradici Tera2321 PCoIP Chip
Memory
512MB
IPS
Yes
2.0 USB Input (6)
Yes
UPoE available with AUPoE* Adapter
Yes
Color
Black Texture
Set (with Stand) (WxHxD)
22.4” x 13.4” x 2"
Set Weight (with Stand)
12.1 Ibs.
Set (without Stand) (WxHxD)
22.4” x 15.3” x10.2”
Set Weight (without Stand)
10.6 Ibs.
Box (WxHxD)
25.3" x 7.6" x 16.1"
Box Weight
15.4 Ibs
Stand
Base detachable, Tilt, Yes / -5° (front), 35° (rear), Swivel (90°), Height (130mm), Pivot
VESA Standard Mount Interface
100mm x 100mm
UL(cUL)
Yes
TUV-Type
Yes
FCC-B, CE
Yes
RoHS
Yes
USB 2.0
6 (4 Back, 2 Side)
Others
LAN (Ethernet)
Headphone Out
Yes
DVI-I out (Dual)
Yes
D-sub in
Yes
Audio Input (Mic In)
Yes
Speaker
Yes (5W x 2)
Type
Adapter (19V DC)
Input
100 ~ 240V
Normal On (typ.)
24W (Monitor) / 29W (Cloud)
Power Save/Sleep Mode (Max)
0.5W (Monitor) / 5.5W (Cloud)
DC Off (Max)
0.5W (Monitor) / 0.5W (Cloud)
Watts in on
24W (D-sub) / 29W (PCoIP)
Watts in sleep
0.5W (D-sub) / 7W (PCoIP)
Watts in off
0.5W (D-sub) / 0.5W (PCoIP)
H-Frequency (Analog)
30 kHz ~ 68 kHz
V-Frequency (Digital)
57 Hz ~ 63 Hz
H-Frequency
30 kHz ~ 68 kHz
V-Frequency
57 Hz ~ 63 Hz
VESA Mount™
100mm x 100mm
Pivot
Yes
Base Detchable
Yes
Tilt
-5°(front)/15°(rear)
Swivel (Angle)
90°
Height (mm)
130mm
Weight Set w/Stand
12.3 Ibs.
Weight Set w/o Stand
7.4 Ibs.
Warranty
3 Years (Parts, Labor, Backlight)
Set w/o Stand (W x H x D)
21.4" x 13.1" x 1.9"
Set w/Stand (W x H x D)
21.4" x 15.2" x 5.1"
Box weight
16.2 lbs
Box (W x H x D)
24.3" x 15.9" x 7.8"
D-Sub
Yes
Power Cord
Yes
