Product Name MAG FORGE 320R AIRFLOW
Case Form Factor Mid Tower
Motherboard Form Factor Support ATX / Micro-ATX / Mini-ITX
I/O Ports
2 x USB 3.2 Gen 1 Type-A
1 x Audio-out
1 x Mic-in
1 x LED Switch
Drive Mount Support 1 x 2.5"
2 x 2.5" / 3.5"
Expansion Slots 7
Maximum GPU Length 390 mm / 15.35 inches
Maximum GPU Height 150 mm / 5.91 inches
Maximum CPU Cooler Height 160 mm / 6.29 inches
Power Supply Support ATX
Maximum PSU Length 200 mm / 7.87 inches (without
2.5"/3.5" HDD tray installation)
Fan Size Support
Front: 3 x 120 mm / 2 x 140 mm
Top: 3 x 120 mm / 2 x 140 mm
Rear: 1 x 120 mm
Side: 2 x 120 mm
PSU Shroud: 2 x 120 mm
Pre-installed Fan Size Front: 3 x 120 mm
Rear: 1 x 120 mm
Pre-installed Fan Type Front: 3 x ARGB Fan
Rear: 1 x ARGB Fan
Radiator Size Support
Front: 120 / 140 / 240 mm
Top: 120 / 240 / 280 / 360 mm
Rear: 120 mm
Dimensions (DxWxH) 472.5 x 210 x 498 mm / 18.60 x 8.26
x 19.60 inches
Net Weight 7.05 kg
Gross Weight 8.35 kg
