Кутия Fractal Design RIDGE WHITE MITX PCIE 4.0, 1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Mini ITX

Кутия Fractal Design RIDGE WHITE MITX PCIE 4.0, 1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Mini ITX

SKU: FD-C-RID1N-12
ID: #37334
Цена: 313,00 лв.
Цената е с вкл. ДДС

Характеристики

Включени вентилатори: Странично: 2x 140 mm PWM
Брой 2.5“ SSD гнезда: 4x 2.5" SSD
Разширителни слотове: 3
Захранване: Не
Размери: Вертикално: 374 x 110 x 395 mm, Хоризонтално: 360 x 375 x 115 mm
Форм фактор: Mini ITX
Цвят: White
Гаранция (месеца): 24

Бърза Поръчка

Описание

  • Dedicated 2.5" drive mounts

    4x included, 4x positions total

  • Expansion slots

    3-slot

  • Front interface

    1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, 1x Combo jack – Audio/Microphone, power button, power LED

  • Total fan mounts

    2x 120/140 mm and 3x 80 mm

  • Side fan

    2x 120/140 mm (2x PWM Aspect fan 140 mm included)

  • Top fan

    3x 80 mm (not included)

  • Cable routing space

    13,8 mm (behind PSU)

  • Tool-less slide with thumbscrew lock

    Side panels

  • Captive thumbscrews

    Side panels

  • Left side panel

    Steel

  • Right side panel

    Steel

Compatibility

  • Motherboard compatibility

    Mini ITX

  • Power supply type

    SFX, SFX-L

  • Side radiator

    120 mm when ≤175mm long GPUs are installed (280 mm without GPU)

  • PSU max length

    SFX-L

  • GPU max length

    325 mm with SSD installed. 335 mm without SSD installed.

  • GPU max height

    125 mm with top fan(s) installed, 137 mm without top fans

  • GPU max thickness

    57 mm with 2x 140 mm fans installed, 82 mm without side fans

  • CPU cooler max height

    70 mm

Dimensions

  • Case dimensions

    Vertical: 374 x 110 x 395 mm, Horizontal: 360 x 375 x 115 mm

  • Case dimensions w/o feet/protrusions/screws

    355 x 95 x 375 mm

  • Net weight

    4.3 kg

  • Package dimensions (LxWxH)

    426 x 167 x 431 mm

  • Gross weight

    5.5 kg

  • Volume

    12.6 liter
