Кутия Fractal Design Core 2300, Mid Tower, 1x USB 3.0, 1x USB 2.0, ATX/Micro ATX/Mini ITX

Fractal Design Core 2300

• Key features
A compact full-ATX case with bottom-mounted PSU, designed for exceptional airflow and cooling
Brushed aluminum-look front panel with a sleek, three-dimensional textured finish
Superior water cooling support for its size, supporting one 240/280mm radiator in the front and a 240mm radiator in the top
Featuring a 120mm rear exhaust fan for great cooling
Total 7 fan slots with two 120mm fans included
Extruded motherboard plate allowing space for additional cable routing; 18.5mm around the motherboard and 13.5mm directly behind it
Supports tall CPU cooler towers, up to 162mm in height
Multiple easy-to-clean dust filters designed into the case to help maintain a dust free interior
Innovative vertical HDD bracket, which simultaneously holds three 3.5" drives and three 2.5" drives
One additional SSD position behind the PSU area with easy installation and access

• Specifications
Mini ITX, Micro ATX ATX motherboard compatibility
2 drive bays of 5,25" or 4 bays 3.5"
4 -2.5" dedicated SSD unit position
7 expansion slots
Graphics cards up to 380mm in length may be instaled. One or more 3.5" hard drives may interfere with side-mounted power connectors on graphics cards longer than 200 mm
Support cooling system: 7 Fan positions (2 fans included)
Filtered fan slots in front and bottom
CPU coolers up to 162 mm in height
Supports ATX PSUs up to 205/185 mm with a bottom 120/140mm fan. When not using any bottom fan location longer PSUs can be used
13.5-18.5 mm of space for cable routing behind the motherboard plate
Extra cable routing holes for usage with mATX motherboards
Available in Black
Case dimensions (WxHxD):195 x 431 x 450mm
Net weight: 5.2 kg
Package dimensions (WxHxD): 270 x 547 x 492mm
Package weight: 6.4 kg

• Cooling system
Front: 2 - 120/140mm fans (included is 1 Fractal Design silent 120mm fan, 1200 RPM speed)
Rear: 1 - 120mm fan (included is 1 Fractal Design silent 120mm fan, 1200 RPM speed)
Top: 2 - 120/140mm fan (not included)
Bottom: 1 - 120mm fan (not included) or 1 - 140mm fan (not included, bottom HDD position must be empty)
Side: 1 -140mm fan (not included)

• Water Cooling compatibility
Front - 240mm radiator, up to 30mm thickness
Front - 240mm radiator, any thickness, push/pull supported (secondary mounting position, three fastening screws per fan only)
Front –Slim 280mm radiator: 15mm fan spacing required for full fastening, radiators with 20mm fan spacing can be used with only the top half fastened to the case (lower ODD slot may need to be unused depending on tube end chamber size)
Top – Slim 240mm radiator (with upper ODD slot occupied by a device no longer than 150mm and with no components on the upper 23 mm on the motherboard that are taller than 34mm)
Rear – 120 mm radiator

• Front interface
1 USB 3.0 and 1 USB 2.0
Audio in/out
Power button with LED (white)
HDD activity LED (white)
