Контролер Axagon PCEM2-D, от PCIe 4x към 2x M.2 (NVMe/SATA) SSD, 2230/2242/2260/2280/22110

SKU: PCEM2-D

ID: #36302

Цена: 27,00 лв.

Цената е с вкл. ДДС

Поддържани формати: M.2 NVMe, M.2 SATA

Интерфейс: PCI Express

Размери: 2230/2242/2260/2280/22110 mm

Гаранция (месеца): 24

Съгласявам се с общите условия и обработка на личните ми данни.

Добави за сравнение

interface	PCI-Express 3.0 + Serial ATA 3.1
number of lines	4-Lane (x4)
rate	8 GB/s bidirectionally (PCI-Express)
rate	6 / 3 / 1.5 Gbit/s (SATA III / SATA II / SATA I)
connector	7-pin SATA data male
compatibility	PCI-Express 1.0a / 1.1 / 2.0 / 2.1 / 3.0
compatibility	x4 / x8 / x16 PCIe slot
compatibility	all SATA I / SATA II / SATA III controllers
Output
interface	NVMe M.2 (PCI-Express) + NGFF M.2 (SATA)
connector	75-pin M.2 B-key
connector	75-pin M.2 M-key
compatibility	all NVMe M.2 SSD
compatibility	all SATA M.2 SSD B-key / B+M-key
total permeability	8 GB/s theoretically (given by PCIe 3.0 4-Lane input)
Supported device
M.2 22110	yes
M.2 2280	yes
M.2 2260	yes
M.2 2242	yes
M.2 2230	yes
double-sided M.2	yes
single-sided M.2	yes
max. disk capacity	all, without limitations
Supported features
TRIM	yes
boot from connected disk	yes
automatic installation	yes
Plug and Play	yes
Other features
indication	2x blue LED - computer connection (permanently on), data transmission (flashes)
Power supply
on the bus	yes (PCI-Express bus power)
OS support
MS Windows	11 / 10 / 8.1 / 8 / 7 (all 32- and 64-bit versions)
MS Windows Server	2016 / 2012 / 2008 R2 (all 32- and 64-bit versions)
Linux	kernel 2.6.31 and higher
