Компютър barebone ASUS PN64-BB7014MD (14-ядрен) Intel Core i5-12700H (2.3/4.7GHz, 24M) DDR5 SO-DIMM, 1x PCIe Gen 4 x4 M.2 NVMe SSD, LAN, Wi-Fi 6Е, Bluetooth, HDMI, DisplayPort, USB Type-C, Free DOS

SKU: PN64-BB7014MD / 90MR00U2-M000E0

ID: #30740

Характеристики

Серия: Barebone

Процесор, серия: Intel Core i7 (14-ядрен)

Процесор: Intel Core i7-12700H 2.3/4.7 GHz

Видео карта, модел: Intel Iris Xe Graphics

Памет, GB: Няма

Памет, тип: DDR5

Памет, слотове: 2 DDR4 SO-DIMM slots

Максимална памет, GB: upt to 32GB, 2 SO-DIMM slots

Тип съхранение: SSD M.2 2280 PCIe 4.0x4 NVMe

HDMI порт: 2 HDMI

Display порт: 1 x DisplayPort

Bluetooth: Bluetooth v5.2

Безжична мрежа: Wireless / Bluetooth

Ethernet (RJ-45) порт: 1 x LAN (RJ-45)

Гаранция (месеца): 36

Направи запитване

Количество: бр.

Доставка до адрес:

Имена:

E-mail:

Телефон:

Съгласие за обработване на личните ми данни за целите на директния маркетинг.

Добави за сравнение

Описание

ASUS PN64-BB7014MD Barebones Intel Core i7-12700H Wifi 6E DP Port VESA 1YR CB


Manufacturer	ASUS
Manufacturer Part No	90MR00U2-M000E0

Marketing Description
ASUS ExpertCenter PN64 is powered by the 12th Gen Intel Core CPU featuring a hybrid processor design. It includes performance-cores (P-cores) dedicated to processing heavy loads and prioritized tasks, as well as efficient-cores (E-cores) catering to background tasks such as web browsing and PowerPoint presentations. This advanced core design enables PN64 to process multiple tasks simultaneously in a efficient way.
Product Features
Superior computing performance ASUS ExpertCenter PN64 delivers superior performance, allowing users to get more done effortlessly, with greater efficiency. Compared to the previous generation PN63-S1 model, PN64 offers more overall system performance, making it perfect for multitasking. Faster and better DDR5 RAM ASUS ExpertCenter PN64 is powered by the 12th Gen Intel Core CPU supporting the next gen memory - DDR5. With DDR5 4800 MHz memory that is faster and more energy efficient than DDR4 3200 MHz memory, PN64 provides excellent performance for daily computing tasks. Ultrafast PCIe 4.0 SSD ASUS ExpertCenter PN64 supports one PCIe Gen 4 x4 SSD to deliver low-latency data transfers at speeds of up to 8 GB/s, that's twice the data transfer speeds of PCIe 3.0. Superfast 2.5 Gbps Ethernet ASUS ExpertCenter PN64 features next-generation 2.5GBASE-T technology for superfast 2.5 Gbps networking speeds, enabling it to make light work of the most data-intensive tasks. Modern, space-saving design Compact and stylish, ASUS ExpertCenter PN64 has a contemporary look that suits any home or office. Ultra-realistic 8K visuals ASUS ExpertCenter PN64 delivers breathtaking 8K visuals at 30 frames per second via the configurable standard DisplayPort or DisplayPort over USB-C. Experience a level of detail that's 4x greater than 4K, or 16x that of traditional FHD output. USB Power Delivery input ASUS ExpertCenter PN64 can draw power from any USB Power Delivery-enabled display or device, eliminating the need for a separate power adapter to create a neater, uncluttered workspace. 4K resolution and quad display support ASUS ExpertCenter PN64 can support up to four 4K displays via two HDMI ports, two DisplayPort over USB-C or other user-configurable ports, without any limitation on the combination used. Configurable port ASUS ExpertCenter PN64 is well-equipped for a wide range of functions and can be used for digital signage, POS systems or intelligent vending machines. The configurable port can be specified with either HDMI, VGA, DisplayPort, or COM ports, as well as 2.5 Gb LAN, for monitors or legacy devices such as barcode scanners and receipt printers. Padlock ring for security The chassis of ASUS ExpertCenter PN64 can be secured with a standard padlock to prevent access to internal components. VESA mount-lockable design ASUS ExpertCenter PN64 can even be locked onto a VESA mount for additional security.
General
Type	PC barebone
Product Form Factor	Mini PC
Embedded Security	Trusted Platform Module (TPM) Security Chip
Colour	Black
Processor / Chipset
CPU	Intel Core i7 (12th Gen) 12700H
Clock Speed	2.3 GHz
Max Turbo Speed	4.7 GHz
Number of Cores	14-core
CPU Qty	1
Max CPU Qty	1
Processor Main Features	Intel Smart Cache
Cache Memory
Installed Size	L3 Cache - 24 MB
Cache Per Processor	24 MB
RAM
Installed Size	32 GB (max)
Technology	DDR5 SDRAM
Effective Memory Speed	4800 MHz
Rated Memory Speed	4800 MHz
Form Factor	SO-DIMM 262-pin
Storage Controller
Type	1 x SATA
Controller Interface Type	SATA 6Gb/s
Optical Storage
Type	No optical drive
Monitor
Monitor Type	None.
Graphics Controller
Graphics Processor	Intel Iris Xe Graphics
Video Interfaces	HDMI, DisplayPort
Networking
Ethernet Controller	Intel I225-V
Wireless LAN Supported	Yes
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6E)
Features	Dual stream (2x2)
Expansion / Connectivity
Interfaces	2 x HDMI 1 x LAN (Gigabit Ethernet) 1 x DisplayPort 1.4 1 x headphones/microphone 3 x USB 3.2 Gen 2 2 x USB-C 3.2 Gen 2
Miscellaneous
Theft/Intrusion Protection	Security lock slot (cable lock sold separately)
Security Slot Type	Kensington security slot
VESA Mounting Interface	Yes
Compliant Standards	UL, VCCI, C-Tick, BSMI, CB, CCC, FCC
Operating System / Software
OS Provided	No operating system
Sustainability Information
ENERGY STAR Certified	Yes
Dimensions & Weight
Width	12 cm
Depth	13 cm
Height	5.8 cm
Weight	1 kg
