Компютър barebone ASUS PN64-BB3012MD (10-ядрен) Intel Core i3-1212P (1.5/4.4GHz, 12MB), DDR5 SO-DIMM, 1x PCIe Gen 4 x4 M.2 NVMe SSD, LAN, Wi-Fi 6Е, Bluetooth, HDMI, DisplayPort, USB Type-C, Free DOS
изчерпан

Компютър barebone ASUS PN64-BB3012MD (10-ядрен) Intel Core i3-1212P (1.5/4.4GHz, 12MB), DDR5 SO-DIMM, 1x PCIe Gen 4 x4 M.2 NVMe SSD, LAN, Wi-Fi 6Е, Bluetooth, HDMI, DisplayPort, USB Type-C, Free DOS

SKU: PN64-BB3012MD / 90MR00U2-M000C0
ID: #30742

Характеристики

Серия: Barebone
Процесор, серия: Intel Core i3 (10-ядрен)
Процесор: Intel Core i3-1212P (1.5/4.4GHz, 12M)
Видео карта, модел: Intel UHD Graphics
Памет, GB: Няма
Памет, тип: DDR5
Максимална памет, GB: up to 64GB, 2 SO-DIMM slots
Тип съхранение: SSD M.2 2280 PCIe 4.0x4 NVMe
HDMI порт: 2 x HDMI
Display порт: 1 x DisplayPort
Bluetooth: Bluetooth v5.2
Безжична мрежа: 802.11ax Wi-Fi 6E
Ethernet (RJ-45) порт: 1 x LAN (Gigabit Ethernet)
Windows OS: Не
Софтуер: Free DOS
Гаранция (месеца): 36

Направи запитване

Описание



ASUS PN64-BB3012MD Barebones Intel Core i3-1220P Wifi 6E DP Port VESA 1YR CB

Manufacturer ASUS
Manufacturer Part No 90MR00U2-M000C0

Marketing Description
ASUS ExpertCenter PN64 is powered by the 12th Gen Intel Core CPU featuring a hybrid processor design. It includes performance-cores (P-cores) dedicated to processing heavy loads and prioritized tasks, as well as efficient-cores (E-cores) catering to background tasks such as web browsing and PowerPoint presentations. This advanced core design enables PN64 to process multiple tasks simultaneously in a efficient way.
Product Features
  • Superior computing performance
    ASUS ExpertCenter PN64 delivers superior performance, allowing users to get more done effortlessly, with greater efficiency. Compared to the previous generation PN63-S1 model, PN64 offers more overall system performance, making it perfect for multitasking.
  • Faster and better DDR5 RAM
    ASUS ExpertCenter PN64 is powered by the 12th Gen Intel Core CPU supporting the next gen memory - DDR5. With DDR5 4800 MHz memory that is faster and more energy efficient than DDR4 3200 MHz memory, PN64 provides excellent performance for daily computing tasks.
  • Superfast 2.5 Gbps Ethernet
    ASUS ExpertCenter PN64 features next-generation 2.5GBASE-T technology for superfast 2.5 Gbps networking speeds, enabling it to make light work of the most data-intensive tasks.
  • Modern, space-saving design
    Compact and stylish, ASUS ExpertCenter PN64 has a contemporary look that suits any home or office.
  • Ultra-realistic 8K Visuals
    ASUS ExpertCenter PN64 delivers breathtaking 8K visuals at 30 frames per second via the configurable standard DisplayPort or DisplayPort over USB-C. Experience a level of detail that's 4x greater than 4K, or 16x that of traditional FHD output.
  • USB Power Delivery input
    ASUS ExpertCenter PN64 can draw power from any USB Power Delivery-enabled display or device, eliminating the need for a separate power adapter to create a neater, uncluttered workspace.
  • 4K resolution and quad display support
    ASUS ExpertCenter PN64 can support up to four 4K displays via two HDMI ports, two DisplayPort over USB-C or other user-configurable ports, without any limitation on the combination used.
  • Configurable port
    ASUS ExpertCenter PN64 is well-equipped for a wide range of functions and can be used for digital signage, POS systems or intelligent vending machines. The configurable port can be specified with either HDMI, VGA, DisplayPort, or COM ports, as well as 2.5 Gb LAN, for monitors or legacy devices such as barcode scanners and receipt printers.
  • Padlock ring for security
    The chassis of ASUS ExpertCenter PN64 can be secured with a standard padlock to prevent access to internal components.
  • VESA mount-lockable design
    ASUS ExpertCenter PN64 can even be locked onto a VESA mount for additional security.
General
Type PC barebone
Product Form Factor Mini PC
Embedded Security Trusted Platform Module (TPM 2.0) Security Chip
Colour Eco black
Processor / Chipset
CPU Intel Core i3 (12th Gen) 1220P
Clock Speed 1.5 GHz
Max Turbo Speed 4.4 GHz
Number of Cores 10-core
CPU Qty 1
Max CPU Qty 1
Processor Main Features Intel Smart Cache
Cache Memory
Installed Size L3 Cache - 12 MB
Cache Per Processor 12 MB
RAM
Installed Size 0 GB / 64 GB (max)
Technology DDR5 SDRAM
Effective Memory Speed 4800 MHz
Rated Memory Speed 4800 MHz
Form Factor SO-DIMM 262-pin
Slots 2 (Total) / 2 (empty)
Hard Drive
Type No HDD
Storage Controller
Type SATA
Controller Interface Type SATA 6Gb/s
Optical Storage
Type No optical drive
Monitor
Monitor Type None.
Graphics Controller
Graphics Processor Intel UHD Graphics
Video Interfaces HDMI, DisplayPort
Networking
Ethernet Controller Intel I225-V
Wireless LAN Supported Yes
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6E)
Features Dual stream (2x2)
Expansion / Connectivity
Bays 1 (total) / 1 (free) x internal 2.5"
Slots 1 M.2 Card
Interfaces 2 x HDMI
1 x LAN (Gigabit Ethernet)
1 x DisplayPort 1.4
1 x headphones/microphone
3 x USB 3.2 Gen 2
2 x USB-C 3.2 Gen 2
Miscellaneous
Theft/Intrusion Protection Security lock slot (cable lock sold separately)
Security Slot Type Kensington security slot
VESA Mounting Interface Yes
Power
Device Type Power adapter
Installed Qty 1
Power Provided 90 Watt
Operating System / Software
OS Provided No operating system
Sustainability Information
ENERGY STAR Certified Yes
Dimensions & Weight
Width 12 cm
Depth 13 cm
Height 5.8 cm
Weight 1 kg
Technical data provided by third party. We assume no liability for errors within these data.
