| Marketing Description |
| Save time, money and plenty of office space with an easy-to-use and compact plotter that delivers high-quality prints every time. |
| Product Features |
- Extreme simplicity
Print with confidence you'll get the results you expect with an intuitive driver and true print preview. You can also send multiple files in one click with HP Click software.
- Fits your office and budget
These compact plotters improve efficiency to meet space limitations and budgetary requirements. Not just a compact plotter, it's also made from up to 30% recycled plastic.
- Fits the way you work
With the HP Smart app you can print virtually from anywhere with your smartphone or tablet. Stand by anything other than a printer.
|
| General |
| Printer Type |
24" large-format printer - ink-jet - colour |
| Localisation |
English, German, French, Italian, Spanish / Europe |
| Printer |
| Inkjet Technology |
HP Thermal Inkjet |
| Ink Palette Supported (Colours) |
4-ink - cyan, magenta, yellow, pigment black |
| Nozzle Configuration |
1376 nozzles |
| Minimum Ink Droplet Size |
12 pl (black), 5.5 pl (colour) |
| Ink Cartridge Configuration |
4 cartridges (1 each: cyan, magenta, yellow, pigment black) |
| Print Speed |
Up to 0.58 min/page - black draft - ANSI D (559 x 864 mm)
Up to 0.58 min/page - colour draft - ANSI D (559 x 864 mm)
Up to 0.58 min/page - black draft - A1 (594 x 841 mm)
Up to 0.58 min/page - colour draft - A1 (594 x 841 mm) |
| Connectivity Technology |
Wireless |
| Interface |
USB 2.0, LAN, Wi-Fi |
| Max Resolution (B&W) |
2400 x 1200 dpi |
| Max Resolution (Colour) |
2400 x 1200 dpi |
| Language Simulation |
URF, JPEG |
| Printer Features |
Print from mobile device, 4.1 kg max roll weight |
| RAM |
| RAM Installed (Max) |
512 MB / 512 MB (max) |
| Media Handling |
| Media Type |
Plain paper, photo paper, bond paper, film, glossy paper, semi-gloss paper, technical paper, self-adhesive paper |
| Max Media Size |
A1 (594 x 841 mm), ANSI D (559 x 864 mm) |
| Min Media Size (Custom) |
210 mm x 279 mm |
| Max Media Size (Custom) |
610 mm x 45.7 m |
| Media Sizes |
ANSI A (Letter) (216 x 279 mm), A4 (210 x 297 mm), A3 (297 x 420 mm), A2 (420 x 594 mm), A1 (594 x 841 mm), ANSI B (Ledger) (279 x 432 mm), ANSI C (432 x 559 mm), ANSI D (559 x 864 mm) |
| Media Thickness Range |
Up to 0.3 mm |
| Media Weight |
60 g/m² - 280 g/m² |
| Networking |
| Networking |
Print server |
| Expansion / Connectivity |
| Connections |
1 x USB 2.0 - 4 pin USB Type B
1 x LAN - RJ-45 |
| Miscellaneous |
| Compliant Standards |
EMC, WEEE, REACH, ERP, EU RoHS, RED, EAEU RoHS |
| Power |
| Power Device |
Power supply - internal |
| Voltage Required |
AC 120/230 V |
| Frequency Required |
50/60 Hz |
| Power Consumption Operational |
35 Watt |
| Power Consumption Stand by |
0.2 Watt |
| Power Consumption Sleep |
2.1 Watt |
| Software / System Requirements |
| Software Included |
HP Support Assistant, HP Click, HP DesignJet Utility |
| Environmental Standards |
| EPEAT Compliant |
EPEAT Gold |
| ENERGY STAR |
Yes |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 1 year |
| Environmental Parameters |
| Min Operating Temperature |
5 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
20 - 80% |
| Sound Emission (Idle) |
16 dBA |
| Sound Emission (Operating) |
42 dBA |
| Dimensions & Weight |
| Width |
101.3 cm |
| Depth |
44 cm |
| Height |
28.5 cm |
| Weight |
21.5 kg |
| Dimensions & Weight (Shipping) |
| Width (Shipping) |
115.5 cm |
| Depth (Shipping) |
57.5 cm |
| Height (Shipping) |
40.5 cm |
| Weight (Shipping) |
28 kg |
