Дънна платка Gigabyte B660M GAMING X, B660, LGA1700, 4 x DDR4, PCIe 4.0 (DP&HDMI)(CF), PCIe 4.0, 4x SATA 6Gb/s, 2x M.2, 3x USB 3.2 Gen 1, mATX
изчерпан
Дънна платка Gigabyte B660M GAMING X, B660, LGA1700, 4 x DDR4, PCIe 4.0 (DP&HDMI)(CF), PCIe 4.0, 4x SATA 6Gb/s, 2x M.2, 3x USB 3.2 Gen 1, mATX
Дънна платка Gigabyte B660M GAMING X, B660, LGA1700, 4 x DDR4, PCIe 4.0 (DP&HDMI)(CF), PCIe 4.0, 4x SATA 6Gb/s, 2x M.2, 3x USB 3.2 Gen 1, mATX
Дънна платка Gigabyte B660M GAMING X, B660, LGA1700, 4 x DDR4, PCIe 4.0 (DP&HDMI)(CF), PCIe 4.0, 4x SATA 6Gb/s, 2x M.2, 3x USB 3.2 Gen 1, mATX
Дънна платка Gigabyte B660M GAMING X, B660, LGA1700, 4 x DDR4, PCIe 4.0 (DP&HDMI)(CF), PCIe 4.0, 4x SATA 6Gb/s, 2x M.2, 3x USB 3.2 Gen 1, mATX
Дънна платка Gigabyte B660M GAMING X, B660, LGA1700, 4 x DDR4, PCIe 4.0 (DP&HDMI)(CF), PCIe 4.0, 4x SATA 6Gb/s, 2x M.2, 3x USB 3.2 Gen 1, mATX

Дънна платка Gigabyte B660M GAMING X, B660, LGA1700, 4 x DDR4, PCIe 4.0 (DP&HDMI)(CF), PCIe 4.0, 4x SATA 6Gb/s, 2x M.2, 3x USB 3.2 Gen 1, mATX

SKU: GA-MB-B660M-GAMING-X
ID: #19009

Характеристики

Поддържани процесори: Intel® Socket LGA1700 for 12th Gen Intel®Core™, Pentium® Gold and Celeron® Processors
CPU Socket: Intel LGA1700
Чипсет: Intel B660
Максимален капацитет RAM памет: up to 128 GB (32 GB single DIMM capacity) of system memory
Поддръжка на Dualchannel: Да
Поддържана памет: DDR4
Честота памет: 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) /3200/3000/2933/2666/2400/2133
Поддръжка на RAID: SATA RAID 0, 1, 5, 10
Graphics технология: CrossFire
Вграден Bluetooth: Не
Wi-Fi Mодул: Не
Други: 256 Mb Flash ROM, UEFI AMI BIOS
Форм фактор: ATX
Гаранция (месеца): 36

Направи запитване

Описание

  • Supports 12th Gen Intel® Core™ Series Processors​​
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs​​
  • 8+1+1 Hybrid Digital VRM Design with DrMOS*​
  • Fully Covered Thermal Design with High Coverage VRM Heatsinks​
  • Fast 2.5 GbE GAMING LAN with Bandwidth Management​​
  • Dual Ultra-Fast NVMe PCIe 4.0 x4 M.2 with Thermal Guard
  • USB 3.2 Gen1 Type-C® for Fast and Versatile Connections​
  • Pre-installed IO Shield for easy and quick installation​
  • High Quality Audio Capacitors and Audio Noise Guard​
  • RGB FUSION 2.0 supports Addressable LED & RGB LED Strips​
  • Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP​​
  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card​​
