| Marketing Description |
The DHP-601AV PowerLine AV2 1000 HD Gigabit Starter Kit uses your home's existing electrical wiring to create a network or extend your existing network1. Share the Internet connection in your hallway with a game console or smart TV in your lounge, or connect a computer the basement where there is no Wi-Fi reception, all without the need to install additional network cabling.
The D-Link DHP-601AV PowerLine AV2 1000 HD Gigabit Starter Kit turns every power socket into a possible network connection to access digital media devices, game consoles, network printers, computers and network storage devices throughout your home.
The DHP-601AV is capable of delivering data transfer rates of up to 1000 Mbps2. This rapid transmission speed makes it ideal for bandwidth-intensive applications, guaranteeing smooth HD video streaming, VoIP calls, and lag-free online gaming. In addition, it prioritizes Internet traffic to help ensure that the movie or music you're streaming don't skip or stutter while web surfing and downloading files at the same time.
The DHP-601AV plugs directly into a power socket, and does not require any additional cables. 128-bit AES data encryption protects your network from unauthorized wire tapping. With hassle-free plug and play installation, the DHP-601AV is an ideal solution to create a wall-to-wall home network.
The DHP-601AV incorporates a power saving mode that automatically places the adapter in sleep mode if no data transmission or reception occurs over a certain period of time, reducing power usage by more than 85%. This helps you save energy automatically without sacrificing performance. |
| Product Features |
- Advanced HomePlug AV2 technology
The D-Link PowerLine AV2 1000 Gigabit Starter Kit (DHP-601AV) delivers the ultimate in wired connectivity for the hard-to-reach areas of your home. Utilizing your home's existing electrical wiring as a reliable high-speed network, the DHP-601AV makes it easy to connect computers, gaming consoles, and media players to your network without additional cables. The DHP-601AV is the ideal solution for getting connected in spaces like offices, bedrooms and other areas of your home that are remotely located from your router.
- Extend your wired network
Extend your Powerline network by adding up to 16 adapters in total. Backward compatible with PowerLine AV, AV+.
- Power saving mode comes in handy
Power Saving mode reduces power consumption up to 85% when compared with existing PowerLine Adapters.
|
| General |
| Packaged Quantity |
2 (specifications are for single item) |
| Device Type |
Powerline adapter kit |
| Enclosure Type |
Wall-pluggable |
| Connectivity Technology |
Wired |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, HomePlug AV (HPAV) 2.0, IEEE 1901 |
| Data Transfer Rate |
1000 Mbps |
| Encryption Algorithm |
128-bit AES |
| Features |
Auto-negotiation |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, HomePlug AV 2.0, IEEE 1901, UL, FCC, LVD |
| Status Indicators |
Port status, power |
| Expansion / Connectivity |
| Interfaces |
1 x HomePlug AV 2.0
LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 |
| Power |
| Power Device |
Internal power supply |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Consumption Operational |
3.7 Watt |
| Miscellaneous |
| Localisation |
Europe |
| Dimensions & Weight |
| Width |
6.22 cm |
| Depth |
3 cm |
| Height |
8.747 cm |
| Weight |
90 g |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
10 - 90% (non-condensing) |
