Dimensions
106 x 63 x 34 mm (4.2 x 2.5 x 1.3")
Output Voltage
54V DC at 1.12A
Rated Voltage
100—240V AC at 50/60Hz
4-pair Powering
Pins 1, 2, 4, 5 (+) and 3, 6, 7, 8 (-)
Clamping Protection
11V Data, 60V power
Data In / PoE
RJ45 Shielded Socket
Inrush Current
<150A peak at 230V AC
Switching Frequency
65 kHz
Max. PoE+ Wattage per Port by PSE
60W
Max. Surge Discharge
1500A (8/20 μs) power
Peak Pulse Current
36A (10/1000 μs) data
Shunt Capacitance
<5 pF data
Surge Protection
Difference and Common Mode
Ambient Storage Temperature
-30 to 70°C (-22 to 158° F)
Ambient Operating Temperature
0 to 40° C (32 to 104° F)
Ambient Operating Humidity
10 to 95% Falsencondensing
