| General |
| Device Type |
DLP projector |
| 3D Capable |
Yes (3D glasses sold separately) |
| Built-in Devices |
Speaker |
| Projector |
| Brightness |
4500 ANSI lumens |
| Contrast Ratio |
20000:1 |
| Image Size |
69 cm - 762 cm |
| Projection Distance |
1.9 m - 9.7 m |
| Throw Ratio |
1.21 - 1.57:1 |
| Digital Zoom Factor |
2x |
| Resolution |
WXGA - WXGA (1280 x 800) (native) / 1920 x 1200 (resized) |
| Native Aspect Ratio |
16:10 |
| Max Sync Rate (V x H) |
120 Hz x 100 kHz |
| Bulb type |
203 Watt |
| Bulb life cycle |
Up to 4000 hour(s) - normal mode
Up to 6000 hour(s) - economic mode
Up to 10000 hour(s) - extreme economic mode |
| Features |
16:9 aspect ratio support, 4:3 aspect ratio support |
| Lens |
| Focus Type |
Manual |
| Lens Aperture |
F/2.59-2.87 |
| Zoom Type |
Manual |
| Zoom Factor |
1.3x |
| Keystone Correction Direction |
Vertical |
| Vertical Keystone Correction |
-40 / +40 |
| Video Input |
| TV System |
NTSC, SECAM, PAL |
| Video Interfaces |
VGA, HDMI, composite video, MHL |
| Video Modes |
720p, 1080i, 1080p |
| Speakers |
| Type |
Integrated |
| Sound Output Mode |
Mono |
| Output Power / Channel |
10 Watt |
| Speakers |
1 x mixed channel |
| Expansion / Connectivity |
| Interfaces |
1 x HDMI - 19 pin HDMI Type A
1 x Mobile High-Definition Link (MHL) / HDMI
1 x VGA input - 15 pin HD D-Sub (HD-15)
1 x VGA output - 15 pin HD D-Sub (HD-15)
1 x serial RS-232
1 x USB - 4 pin USB Type A
1 x audio line-in - mini-phone 3.5 mm
1 x audio line-out - mini-phone 3.5 mm
1 x composite video input - RCA
1 x USB - mini-USB Type B |
| Miscellaneous |
| Included Accessories |
Carrying case, remote control, battery for remote control, security card |
| Cables Included |
1 x VGA cable |
| Power |
| Power Source |
AC |
| Voltage Required |
AC 100-240 V (50/60 Hz) |
| Power Consumption Operational |
260 Watt |
| Power Consumption Stand by |
0.5 Watt |
| Dimensions & Weight |
| Width |
30 cm |
| Depth |
22 cm |
| Height |
9.2 cm |
| Weight |
2.4 kg |
